IEEE 1284-Compatible Parallel Interface
—
CD1283
Datasheet
79
Note:
For synchronous systems, it is necessary to determine the clock cycle number so that interface
circuitry can stay in lock-step with the device. CLK numbers can be determined if RESET* is
released within the range t
a
–
t
b
; t
a
is defined as 10 ns minimum, after the rising edge of the clock; t
b
is defined as 5 ns minimum, before the next rising edge of the clock. If these conditions are met, the
cycle starting after the second rising edge will be C1. See the synchronous timing diagrams for
additional information. Clock numbers are not important in asynchronous systems.
The following timing numbers are for the back-to-back asynchronous DMA timing diagrams.
t
25
23
Hold time, DMAACK* active (DMA read/write)
3 CLK
t
26
23
Delay, data valid after falling edge DMAACK* (DMA read)
0.5 CLK
+
20
1.5 CLK
+
25
ns
t
27
23
Hold time, data valid after rising edge DMAACK* (DMA read)
10
30
ns
t
28
23
25
Inactive time, DMAACK* (DMA read/write)
10
ns
t
29
23
25
Hold time, DMAREQ* rising edge after
DMAACK* falling edge (DMA read/write)
10
1 CLK
+
15
ns
t
30
25
Hold time, DMAACK* active (DMA write)
2.5 CLK
t
31
25
Delay, data valid after falling edge DMAACK* (DMA write)
1.5 CLK
NOTES:
1. Timing numbers for RESET* and CLK are valid for both asynchronous and synchronous specifications. The device will
operate on any clock with a 40
–
60 or better duty cycle.
2. On host-I/O cycles, immediately following SVCACK* cycles and writes to EOSRR, DTACK* will be delayed by 20 CLKs (1 ms
@ 20 MHz; 800 ns @ 25 MHz). On systems that do not use DTACK* to signal the end of the I/O cycle, wait states or some
other form of delay generation must be used to assure that the CD1283 is not accessed until after this time period.
3. As TCLK increases, device performance decreases. A minimum clock frequency of 25 MHz is required to guarantee specified
performance. The recommended maximum TCLK is 1000 ns.
4. DTACK* sources current (drives
‘
high
’
) until the voltage on the DTACK* line is approximately 1.5 V; then DTACK* goes to the
‘
open-drain
’
(high-impedance) state.
Figure 17. Reset Timing
Table 12. Asynchronous Timing Reference Parameters
(Sheet 2 of 2)
Timing
No.
Figure
Parameter
MIN
MAX
Unit
t
1
V
CC
CLK
RESET*
t
a
t
b
C2
C1
C2
C1
C2
CLK/2
