SPEAR-09-B042
Standard customization
Key features
●
Meets SD host controller standard specification version 2.0
●
Meets SDIO card specification version 2.0
●
Meets SD memory card specification draft version 2.0
●
Meets SD memory card security specification version 1.01
●
Meets MMC specification version 3.31 and 4.2
●
Supports both DMA and Non-DMA mode of operation
●
Supports MMC plus and MMC mobile
●
Card detection (insertion/removal)
●
Password protection of cards
●
Host clock rate variable between 0 and 52 MHz
●
Supports 1-bit, 4-bit and 8-bit SD modes and SPI mode
●
Supports MultiMediaCard interrupt mode
●
Allows card to interrupt host in 1-bit, 4-bit, 8-bit SD modes and SPI mode.
●
Up to 100 Mbit/s data rate using 4 parallel data lines (sd4-bit mode)
●
Up to 416 Mbit/s data rate using 8-bit parallel data lines (sd8-bit mode)
●
Cyclic redundancy check CRC7 for command and CRC16 for data integrity
●
Designed to work with I/O cards, read-only cards and read/write cards
●
Error correction code (ECC) support for MMC4.2 cards
●
Supports read wait control, suspend/resume operation
●
Supports FIFO overrun and Under run condition by stopping the SD clock
9.4.3
Flexible static memory controller
Main features of the FSMC are listed below:
●
Provides an interface between AHB system bus and external parallel memory devices.
●
Interfaces static memory-mapped devices including RAM, ROM and synchronous burst
Flash.
●
For SRAM, ROM and Flash 8/16-bit wide, external memory and data paths are
provided.
●
FSMC performs only one access at a time and only one external device is accessed.
●
Little-endian and big-endian memory architectures.
●
AHB burst transfer handling to reduce access time to external devices.
●
Supplies an independent configuration for each memory bank.
●
Programmable timings to support a wide range of devices.
–
Programmable wait states (up to 31).
–
Programmable bus turnaround cycles (up to 15).
–
Programmable output enable and write enable delays (up to 15).
●
Independent chip select control for each memory bank.
●
Shares the address bus and the data bus with all the external peripherals.
●
Only chips selects are unique for each peripheral.
●
External asynchronous wait control.
●
Configurable size at reset for boot memory bank using external control pins.
