38
56F8346 Technical Data
MOTOROLA
Preliminary
4.4 Data Map
4.5 Flash Memory Map
Figure 4-1 illustrates the Flash Memory (FM) map on the system bus.
The Flash Memory is divided into three functional blocks. The Program and boot memories reside on the
Program Memory buses. They are controlled by one set of banked registers. Data Memory Flash resides on
the Data Memory buses and is controlled separately, having its own set of banked registers.
The top nine words of the Program Memory Flash are treated as special memory locations. The content of
these words is used to control the operation of the Flash Controller. Because these words are part of the Flash
Memory content, their state is maintained during power-down and reset. During chip initialization, the
content of these memory locations is loaded into Flash Memory control registers, detailed in the Flash
Memory chapter of the 56F8300 Peripheral User Manual. In the 56F8346, these configuration parameters
are located between $00_FFF7 and $00_FFFF.
Table 4-6 Data Memory Map1
1.
All addresses are 16-bit Word addresses, not byte addresses.
Begin/End
Address
EX = 02
2.
In the Operation Mode Register (OMR).
EX = 1
X:$FF FFFF
X:$FF FF00
EOnCE
256 locations allocated
EOnCE
256 locations allocated
X:$FF FEFF
X:$01 0000
External Memory
X:$00 FFFF
X:$00 F000
On-Chip Peripherals
4096 location allocated
On-Chip Peripherals
4096 location allocated
X:$00 EFFF
X:$00 2000
External Memory
X:$00 1FFF
X:$00 1000
On-Chip Data Flash
8KB
X:$00 0FFF
X:$00 0000
On-Chip Data RAM
8KB3
3.
The Data RAM is organized as a 2K x 32-bit memory to allow single-cycle long-word operations.
