5–2
5.2
Recommended Operating Conditions
MIN
NOM
MAX
UNIT
Supply voltage, VCC
Input voltage, VI
High-level input voltage, VIH
Low-level input voltage, VIL
4.75
5
5.25
V
0
VCC
VCC
0.8
V
2
V
0
V
Clock frequency
BCLK
25
MHz
SCLK
49.152
TSB12C01A
115
Virtual junction temperature, TJ
TSB12C01AI
125
°
C
TSB12C01AM
150
TSB12C01A
0
70
Operating free-air temperature, TA
TSB12C01AI
–40
85
°
C
TSB12C01AM
–55
125
Actual junction temperature is a function of ambient temperature, package selection, power dissipation, and air flow.
Customer is responsible for maintaining the junction temperature within the recommended operating conditions.
Operating device at junction temperatures higher than what is recommended will cause device to operate outside the
characterization models established during device simulation and may affect the reliability performance.
5.3
Electrical Characteristics Over Recommended Ranges of Supply Voltage
and Operating Free-Air Temperature (unless otherwise noted)
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
VOH
VOL
VIT+
VIT–
IIL
IIH
High-level output voltage
IOH = –4 mA
IOL = 4 mA
VCC– 0.8
V
Low-level output voltage
0.5
V
Positive-going input threshold voltage
2
V
Negative-going input threshold voltage
0.8
V
μ
A
μ
A
Low-level input current
VI = GND
VI = VCC
VO = VCC or GND,
See Note 4
–1
High-level input current
1
IOZ
High-impedance-state output current
±
10
μ
A
ICC
Supply current
No load on outputs,
SCLK = 49.152 MHz
BCLK = 25 MHz
150
mA
PZ package
input terminals
5
WN package
input terminals
6
Ci
Input capacitance
PZ package
bidirectional
terminals
VCC = 5 V,
TA = 25
°
C
13
pF
WN package
bidirectional
terminals
7
Co
Output capacitance
Out ut ca acitance
PZ package
8
pF
WN package
7
All typical values are at VCC = 5 V and TA = 25
°
C.
NOTE 4: All outputs are in the high-impedance state.
