4–9
4.8
The format of the receive self-ID packet is shown in Figure 4–11. The first quadlet is the packet header with
the special tCode of Eh. The quadlets that follow are a concatenation of all received self-ID packets. The
last quadlet contains the final packet status. See IEEE 1394-1995 standard, paragraph 4.3.4.1, for
additional information about self-ID packets.
Receive Self-ID
0
1 2
3
4
5 6
7
8
9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
tCode
priority
spd
ackSent
Self-ID Packet Data
Figure 4–11. Receive Self-ID Format
Table 4–11. Isochronous-Receive Functions
FIELD NAME
DESCRIPTION
tCode
This field carries the transaction code for this packet (tCode = Eh).
priority
This field carries the priority level for this packet.
Self-ID packet data
This field contains a concatenation of all the Self-ID packets received.
spd
This field indicates the speed at which this packet was sent (00 = 100 Mbits/s, 01 = 200 Mbits/s,
10 = 400 Mbits/s, and 11 is undefined).
ackSent
This field holds the acknowledge sent by the receiver for this packet.
