Introduction
17
December 2004
SGUS053
Table 22. Signal Descriptions (Continued)
NAME
DESCRIPTION
PU/PD§
I/O/Z
PIN
NO.
NAME
DESCRIPTION
PU/PD§
I/O/Z
172-PIN
HFG
TESTSEL
131
I
PD
Test Pin. Reserved for TI. Must be connected to ground.
XRS
156
I/O
PU
Device Reset (in) and Watchdog Reset (out).
Device reset. XRS causes the device to terminate execution. The PC will point
to the address contained at the location 0x3FFFC0. When XRS is brought to a
high level, execution begins at the location pointed to by the PC. This pin is
driven low by the DSP when a watchdog reset occurs. During watchdog reset,
the XRS pin will be driven low for the watchdog reset duration of 512 XCLKIN
cycles.
The output buffer of this pin is an open-drain with an internal pullup (100
A,
typical). It is recommended that this pin be driven by an open-drain device.
TEST1
66
I/O
Test Pin. Reserved for TI. On F281x devices, TEST1 must be left unconnected.
TEST2
65
I/O
Test Pin. Reserved for TI. On F281x devices, TEST2 must be left unconnected.
TRST
132
I
PD
JTAG test reset with internal pulldown. TRST, when driven high, gives the scan
system control of the operations of the device. If this signal is not connected or
driven low, the device operates in its functional mode, and the test reset signals
are ignored.
NOTE: Do not use pullup resistors on TRST; it has an internal pulldown device.
In a low-noise environment, TRST can be left floating. In a high-noise
environment, an additional pulldown resistor may be needed. The value of this
resistor should be based on drive strength of the debugger pods applicable to
the design. A 2.2-k
resistor generally offers adequate protection. Since this is
application-specific, it is recommended that each target board is validated for
proper operation of the debugger and the application.
TCK
133
I
PU
JTAG test clock with internal pullup
TMS
123
I
PU
JTAG test-mode select (TMS) with internal pullup. This serial control input is
clocked into the TAP controller on the rising edge of TCK.
TDI
128
I
PU
JTAG test data input (TDI) with internal pullup. TDI is clocked into the selected
register (instruction or data) on a rising edge of TCK.
TDO
124
O/Z
JTAG scan out, test data output (TDO). The contents of the selected register
(instruction or data) is shifted out of TDO on the falling edge of TCK.
EMU0
133
I/O/Z
PU
Emulator pin 0. When TRST is driven high, this pin is used as an interrupt to
or from the emulator system and is defined as input/output through the JTAG
scan.
EMU1
143
I/O/Z
PU
Emulator pin 1. When TRST is driven high, this pin is used as an interrupt to
or from the emulator system and is defined as input/output through the JTAG
scan.
Typical drive strength of the output buffer for all pins is 4 mA except for TDO, XCLKOUT, XF, XINTF, EMU0, and EMU1 pins, which are 8 mA.
I = Input, O = Output, Z = High impedance
§ PU = pin has internal pullup; PD = pin has internal pulldown
