HM17CM256
- 43 -
(28) PARTIAL DISPLAY FUNCTION
HM17CM256 can realize the partial display at graphic display area on LCD panel.
Partial display is used with lower duty than normal state at driving.
And so, HM17CM256 can drive the LCD panel with lower bias ratio, lower boosting times and
lower LCD driving voltages, and that can drive the LCD panel with lower power consumption.
This function is suitable for calendar or clock display at mobile information apparatus.
PARTIAL DISPLAY IMAGE
Normal display
The next sequence should be followed carefully to realize partial display function.
Setting the power supply circuit
partial display
~
boosting coefficient
electric volume
bias ratio
~
~
~
duty ratio
display start line setting
display start command
~
~
and so on.
HYUNDAI
LCD DRIVER
Low Power and
Low Voltage
LCD DRIVER
Any display states
DISPLAY OFF(ON/OFF=”0”)
built-in power source OFF(DCON=”0”, AMPON=”0”)
WAIT
Setting the display-related function
Built-in power source ON(DCON=”1”, AMPON=”1”)
WAIT
Display ON(ON/OFF=”1”)
Partial display state
