DAC1627D1G25
All information provided in this document is subject to legal disclaimers.
NXP B.V. 2011. All rights reserved.
Objective data sheet
Rev. 1 — 29 April 2011
29 of 69
NXP Semiconductors
DAC1627D1G25
Dual 16-bit DAC: up to 1.25 Gsps; x2, x4 and x8 interpolating
The settings applied to DAC_A_GAIN_COARSE[3:0] (register 17h; see
Table 46
and
register 18h see
Table 47
;) and to DAC_B_GAIN COARSE[3:0]
(register 19h; see
Table 48
and register 1Ah see
Table 49
;) define the coarse variation of
the full-scale current (see
Table 19
).
Table 19.
Default settings are shown highlighted.
DAC_GAIN_COARSE[3:0]
Decimal
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
The settings applied to DAC_A_GAIN_FINE[5:0] (see register 17h in
Table 46
) and to
DAC_B_GAIN_FINE[5:0] (see register 19h in
Table 48
) define the fine variation of the
full-scale current (see
Table 20
).
Table 20.
Default settings are shown highlighted.
DAC_GAIN_FINE[5:0]
Decimal
32
...
0
...
+31
10.13 Digital offset adjustment
The DAC1627D1G25 provides digital offset correction (bits DAC_A_OFFSET[7:0] in
Table 40
and bits DAC_A_OFFSET[15:8] in
Table 41
and register DAC_B_OFFSET[7:0]
in
Table 42
and bits DAC_B_OFFSET[15:8] in
Table 43
) which can be used to adjust the
common-mode level at the output of each DAC. It adds an offset at the end of the digital
part, just before the DACs.
Table 21
shows the range of variation of the digital offset.
I
O(fs)
coarse adjustment
I
O(fs)
(mA)
Binary
0000
0001
0010
0011
0100
0101
0110
0111
1000
1001
1010
1011
1100
1101
1110
1111
6.95
8.4
9.85
11.3
12.75
14.2
15.65
17.1
18.55
20
21.45
22.9
24.35
25.8
27.25
28.7
I
O(fs)
fine adjustment
Δ
I
O(fs)
(%)
Two’s complement
10 0000
...
00 0000
...
01 1111
11
...
0
...
+11
