TA1310N
2001-06-25
64
(TEST CONDITIONS VCC = 5 V and 9 V, Ta = 25 ± 3°C)
SW MODE & SUB ADDRESS & DATA
NOTE
ITEM
S03
S04
S05
S06
S07
S08
S09
S10
S54
MEASUREMENT METHOD
T26
Analog RGB Gain
B
ON
A
OFF
C
1) Input signal 1 (f = 100 kHz, picture period amplitude = 0.2 Vp-p) to pin 3.
2) Measure the picture period amplitude of pin 13 (v13R).
3) As in steps 1) and 2) above, input to pin 4 and measure pin 14 (v14G),
then input to pin 5 and measure pin 15 (v15B).
4) GTXR = v13R / 0.2
GTXG = v14G / 0.2
GTXB = v15B / 0.2
T27
Analog RGB
Frequency Characteristics
B
ON
A
OFF
C
1) Input signal 1 (f = 8 MHz, picture period amplitude = 0.2 Vp-p) to pin 3.
2) Measure the picture period amplitude of pin 13.
(v13R 8 MHz)
3) As in steps 1) and 2)above, input to pin 4 and measure pin 14, then input
to pin 5 and measure pin 15. (v14G 8 MHz, v15B 8 MHz)
4) Calculate the frequency characteristics from the above results and the
results obtained in T26.
GfTXR = 20 ×og (v13R 8 MHz / v13R)
GfTXG = 20 ×og (v14G 8 MHz / v14G)
GfTXB = 20 ×og (v15B 8 MHz / v15B)
T28
Analog RGB Input D Range
B
ON
A
OFF
C
1) Set the subaddress (00: unicolor) data to min(00).
2) Input signal 2 to pin 3 and gradually increase picture amplitude A.
3) When the voltage during the picture period of pin 13 stops changing,
measure picture amplitude A (DR13).
4) Repeat steps (2) and (3) above under the following conditions:
Input to pin 4, measure the voltage during the picture period of pin 14
(DR14).
Input to pin 5, measure the voltage during the picture period of pin 15
(DR15).
