CONFIDENTIAL
44
Mitsubishi microcomputers
M16C / 24 Group
SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER
Preliminary Specifications REV.B
Specifications in this manual are tentative and subject to change
Universal Serial Bus
2.18 Universal Serial Bus
The Universal Serial Bus (USB) has the following features:
Complete USB Specication (version 1.0) Compatibility
Error-handling capabilities
FIFOs:
Endpoint 0:
IN 32-byte
OUT 32-byte
Endpoint 1:
IN 128-byte
OUT 128-byte
Endpoint 2:
IN 32-byte
OUT 32-byte
Endpoint 3:
IN 32-byte
OUT 32-byte
Endpoint 4:
IN 32-byte
OUT 32-byte
Nine Endpoints - Control endpoint (Endpoint 0 - bidirectional) plus four IN and four OUT
endpoints
Complete Device Conguration
Supports All Device Commands
Supports Full-Speed Functions
Support of All USB Transfer Types:
Isochronous
Bulk
Control
Interrupt
Suspend/Resume Operation
On-chip USB Transceiver with voltage converter
Start-of-frame interrupt and output pin
USB Function Control Unit (USB FCU)
The implementation of the USB by this device is accomplished chiefly through the device’s USB
Function Control Unit (See Figure 29). The Function Control Unit’s overall purpose is to handle the
USB packet protocol layer. The Function Control Unit notifies the MCU that a valid token has been
received. When this occurs, the data portion of the token is routed to the appropriate FIFO. The MCU
transfers the data to, or from, the host by interacting with that endpoint’s FIFO and CSR register.
The USB Function Control Unit is composed of five sections:
Serial Interface Engine (SIE)
Generic Function Interface (GFI)
Serial Engine Interface Unit (SIU)
Microcontroller Interface (MCI)
USB Transceiver
Serial Interface Engine
The SIE interfaces to the USB serial data and handles deserialization/serialization of data, NRZI encoding
decoding, clock extraction, CRC generation and checking, bit stuffing, and other specifications pertaining to
the USB protocol such as handling inter-packet time-outs and packet ID (PID) decoding.
