SMJ34020A
GRAPHICS SYSTEM PROCESSOR
SGUS011D -- APRIL 1991 -- REVISED SEPTEMBER 2004
65
POST OFFICE BOX 1443
HOUSTON, TEXAS 77251--1443
absolute maximum ratings over operating case temperature range
Maximum supply voltage, VCC (see Note 1)
7 V
....................................................
Input voltage range
-- 0.3Vto7V
................................................................
Off-state output voltage range
-- 2 V to 7 V
........................................................
Operating case termperature range, TC
-- 55°C to 125°C
...........................................
Storage temperature range, Tstg
-- 65°C to 150°C
..................................................
Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not
implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
NOTE 1: All voltage values are with respect to VSS.
recommended operating conditions
MIN
NOM
MAX
UNIT
V
S ppl
oltage
34020A-32
4.5
5
5.5
V
VCC
Supply voltage
34020A-40
4.75
5
5.25
V
VSS
Supply voltage (see Note 2)
0
V
IOH
High-level output current
400
μA
IOL
Low-level output current
2
mA
TC
Operating case temperature (see Note 3)
-- 55
125
°C
NOTE 2: A minimum inductance path between the VSS pins and system ground must be provided to minimize noise on VSS.
NOTE 3: TC MAX at maximum rated operating conditions at any point on case. TC MIN at initial (time zero) power up.
