XC167
Derivatives
Functional Description
Data Sheet
27
V1.1, 2003-06
Preliminary
The XC167 also provides an excellent mechanism to identify and to process exceptions
or error conditions that arise during run-time, so-called ‘Hardware Traps’. Hardware
traps cause immediate non-maskable system reaction which is similar to a standard
interrupt service (branching to a dedicated vector table location). The occurence of a
hardware trap is additionally signified by an individual bit in the trap flag register (TFR).
Except when another higher prioritized trap service is in progress, a hardware trap will
interrupt any actual program execution. In turn, hardware trap services can normally not
be interrupted by standard or PEC interrupts.
Table 5 shows all of the possible exceptions or error conditions that can arise during run-
time:
Table 5
Hardware Trap Summary
Exception Condition
Trap
Flag
Trap
Vector
Location1)
1)
Register VECSEG defines the segment where the vector table is located to.
Trap
Number
Trap
Priority
Reset Functions:
– Hardware Reset
– Software Reset
– W-dog Timer Overflow
–
RESET
xx’0000H
00H
III
Class A Hardware Traps:
– Non-Maskable Interrupt
– Stack Overflow
– Stack Underflow
– Software Break
NMI
STKOF
STKUF
SOFTBRK
NMITRAP
STOTRAP
STUTRAP
SBRKTRAP
xx’0008H
xx’0010H
xx’0018H
xx’0020H
02H
04H
06H
08H
II
Class B Hardware Traps:
– Undefined Opcode
– PMI Access Error
– Protected Instruction
Fault
– Illegal Word Operand
Access
UNDOPC
PACER
PRTFLT
ILLOPA
BTRAP
xx’0028H
0AH
I
Reserved
–
[2CH –
3CH]
[0BH –
0FH]
–
Software Traps
– TRAP Instruction
––
Any
[xx’0000H –
xx’01FCH]
in steps
of 4H
Any
[00H –
7FH]
Current
CPU
Priority
