MMDFS2P102
http://onsemi.com
2
SCHOTTKY RECTIFIER MAXIMUM RATINGS (TJ = 25°C unless otherwise noted)
Peak Repetitive Reverse Voltage
DC Blocking Voltage
VRRM
VR
20
Volts
IO
1.0
Amps
Ifrm
2.0
Amps
NonRepetitive Peak Surge Current
(Surge applied at rated load conditions, halfwave, single phase, 60 Hz)
Ifsm
20
Amps
THERMAL CHARACTERISTICS SCHOTTKY AND MOSFET
Thermal Resistance JunctiontoAmbient (Note 2) MOSFET
RqJA
167
°C/W
Thermal Resistance JunctiontoAmbient (Note 3) MOSFET
RqJA
100
Thermal Resistance JunctiontoAmbient (Note 3.) MOSFET
RqJA
62.5
Thermal Resistance JunctiontoAmbient (Note 2) Schottky
RqJA
204
Thermal Resistance JunctiontoAmbient (Note 3) Schottky
RqJA
122
Thermal Resistance JunctiontoAmbient (Note 1) Schottky
RqJA
83
Operating and Storage Temperature Range
Tj, Tstg
55 to 150
1. Mounted on 2″ square FR4 board (1″ sq. 2 oz. Cu 0.06″ thick single sided), 10 sec. max.
2. Mounted with minimum recommended pad size, PC Board FR4.
3. Mounted on 2″ square FR4 board (1″ sq. 2 oz. Cu 0.06″ thick single sided), Steady State.
