Signal Pins
56F8323 Technical Data, Rev. 11.0
Freescale Semiconductor
25
Preliminary
ISA0
(GPIOA9)
16
Schmitt
Input
Schmitt
Input/
Output
Input
ISA0 — This input current status pin is used for top/bottom pulse
width correction in complementary channel operation for PWMA.
Port A GPIO — This GPIO pin can be individually programmed as
an input or output pin.
In the 56F8323, the default state after reset is ISA0.
In the 56F8123, the default state is not one of the functions offered
and must be reconfigured.
ISA1
(GPIOA10)
18
Schmitt
Input
Schmitt
Input/
Output
Input
ISA1 — This input current status pin is used for top/bottom pulse
width correction in complementary channel operation for PWMA.
Port A GPIO — This GPIO pin can be individually programmed as
an input or output pin.
In the 56F8323, the default state after reset is ISA1.
In the 56F8123, the default state is not one of the functions offered
and must be reconfigured.
ISA2
(GPIOA11)
19
Schmitt
Input
Schmitt
Input/
Output
Input
ISA2 — This input current status pin is used for top/bottom pulse
width correction in complementary channel operation for PWMA.
Port A GPIO — This GPIO pin can be individually programmed as
an input or output pin.
In the 56F8323, the default state after reset is ISA2.
In the 56F8123, the default state is not one of the functions offered
and must be reconfigured.
ANA0
26
Input
ANA0 - 3 — Analog inputs to ADCA, Channel 0
ANA1
27
ANA2
28
ANA3
29
ANA4
30
Input
ANA4 - 7 — Analog inputs to ADCA, Channel 1
ANA5
31
ANA6
32
ANA7
33
VREFH
40
Schmitt
Input
VREFH — Analog Reference Voltage High
Table 2-2 Signal and Package Information for the 64-Pin LQFP
Signal Name
Pin No.
Type
State During
Reset
Signal Description
