CAN looping mode
If the CAN_Loop_en bit in control register 4 is set the TXDC input is mapped directly to the
RXDC pin. This mode can be used in combination with the CAN receive only mode, to run
diagnosis for the CAN protocol handler of the micro controller.
2.10
Serial peripheral interface (ST SPI standard)
A 24 bit SPI is used for bi-directional communication with the micro controller.
During active mode, the SPI
●
Triggers the watchdog
●
Controls the modes and status of all L99PM62XP modules (incl. input and output
drivers)
●
Provides driver output diagnostic
●
Provide L99PM62XP diagnostic (incl. over temperature warning, L99PM62XP
operation status)
The SPI can be driven by a micro controller with its SPI peripheral running in following
mode:
CPOL = 0 and CPHA = 0.
For this mode input data is sampled by the low to high transition of the clock CLK, and
output data is changed from the high to low transition of CLK.
This device is not limited to micro controller with a built-in SPI. Only three CMOS-compatible
output pins and one input pin is needed to communicate with the device. A fault condition
can be detected by setting CSN to low. If CSN = 0, the DO-pin reflects the global error flag
(fault condition) of the device.
Chip select not (CSN)
The input pin is used to select the serial interface of this device. When CSN is high, the
output pin (DO) is in high impedance state. A low signal activates the output driver and a
serial communication can be started. The state during CSN = 0 is called a communication
frame.
If CSN = low for t > tCSNfail the DO output is switched to high impedance in order to not block
the signal line for other SPI nodes.
Serial data in (DI)
The input pin is used to transfer data serial into the device. The data applied to the DI is
sampled at the rising edge of the CLK signal and shifted into an internal 24 bit shift register.
At the rising edge of the CSN signal the contents of the shift register is transferred to Data
Input Register. The writing to the selected data input register is only enabled if exactly 24
bits are transmitted within one communication frame (i.e. CSN low). If more or less clock
pulses are counted within one frame the complete frame is ignored. This safety function is
implemented to avoid an activation of the output stages by a wrong communication frame.
Note:
Due to this safety functionality a daisy chaining of SPI is not possible. Instead, a parallel
operation of the SPI bus by controlling the CSN signal of the connected IC's is
recommended.
