56F8123 Package and Pin-Out Information
56F8323 Technical Data, Rev. 11.0
Freescale Semiconductor
135
Preliminary
Figure 11-3 64-pin LQFP Mechanical Information
AB
e/2
e
60X
X=A, B OR D
C
L
VIEW Y
S
0.05
q
1
( 2)
0.25
GAGE PLANE
SEATING
PLANE
A2
(S)
R1
2X R
(L1)
(L2)
L
A1
VIEW AA
b1
SECTION AB-AB
b
c1
c
PLATING
BASE METAL
ROTATED 90 CLOCKWISE
°
A-B
M
0.08
D
C
64
0.2 HA-B D
1
49
48
17
16
32
33
B
E/2
E
E1
D1
D/2
D
D1/2
3X
VIEW Y
A
4X
VIEW AA
0.08 C
q
( 3)
4X
4X 16 TIPS
0.2 CA-B D
E1/2
A
D
C
H
X
DIM
MIN
MAX
MILLIMETERS
A
---
1.60
A1
0.05
0.15
A2
1.35
1.45
b
0.17
0.27
b1
0.17
0.23
c
0.09
0.20
c1
0.09
0.16
D
12.00 BSC
D1
10.00 BSC
e
0.50 BSC
E
12.00 BSC
E1
10.00 BSC
L
0.45
0.75
L1
1.00 REF
L2
0.50 REF
R1
0.10
0.20
S
0.20 REF
q
0
7
q
0
---
q
12 REF
q
12 REF
NOTES:
1.
DIMENSIONS AND TOLERANCING PER ANSI Y14.5M,
1982.
2.
CONTROLLING DIMENSION: MILLIMETER.
3.
DATUM PLANE DATUM H IS LOCATED AT BOTTOM OF
LEAD AND IS COINCIDENT WITH THE LEAD WHERE
THE LEAD EXITS THE PLASTIC BODY AT THE BOTTOM
OF THE PARTING LINE.
4.
DATUMS A, B AND D TO BE DETERMINED AT DATUM
PLANE DATUM C.
5.
DIMENSIONS D AND E TO BE DETERMINED AT
SEATING PLANE DATUM C.
6.
DIMENSIONS D1 AND E1 DO NOT INCLUDE MOLD
PROTRUSION. ALLOWABLE PROTRUSION IS 0.25 PER
SIDE.
7.
DIMENSION b DOES NOT INCLUDE DAMBAR
PROTRUSION. DAMBAR PROTRUSION SHALL NOT
CAUSE THE b DIMENSION TO EXCEED 0.35. MINIMUM
SPACE BETWEEN PROTRUSION AND ADJACENT
LEAD OR PROTRUSION 0.07.
