MB95130MB Series
5
(Continued)
*1 : For ROM capacity and RAM capacity, refer to “
■ MEMORY LINEUP”.
*2 : For details of option, refer to “
■ MASK OPTION”.
*3 : Specify clock mode when ordering MASK ROM.
*4 : Embedded Algorithm is a trade mark of Advanced Micro Devices Inc.
Note : Part number of evaluation product in MB95130MB series is MB95FV100D-103.
When using it, the MCU board (MB2146-303A) is required.
Part number
Parameter
MB95136MB
MB95
F133MBS/
F134MBS/
F136MBS
MB95
F133NBS/
F134NBS/
F136NBS
MB95
F133MBW/
F134MBW/
F136MBW
MB95
F133NBW/
F134NBW/
F136NBW
MB95
F133JBS/
F134JBS/
F136JBS
MB95
F133JBW/
F134JBW/
F136JBW
Peripheral
functions
8/16-bit
compound
timer
(1 channel)
Each channel of the timer can be used as “8-bit timer x 2 channels” or “16-bit timer x 1 channel”.
Built-in timer function, PWC function, PWM function, capture function and square wave-form output
Count clock: 7 internal clocks and external clock can be selected.
16-bit PPG
(1 channel)
PWM mode or one-shot mode can be selected.
Counter operating clock: Eight selectable clock sources
Support for external trigger start
8/16-bit PPG
(1 channel)
Each channel of the PPG can be used as “8-bit PPG x 2 channels” or “16-bit PPG x 1 channel”.
Counter operating clock: Eight selectable clock sources
Watch
counter
(for dual
clock
product)
(1 channel)
Count clock : Four selectable clock sources (125 ms, 250 ms, 500 ms, or 1 s)
Counter value can be set from 0 to 63. (Capable of counting for 1 minute when selecting clock
source 1 second and setting counter value to 60)
Watch
prescaler
(for dual
clock
product)
(1 channel)
Four selectable interval times (125 ms, 250 ms, 500 ms, or 1 s)
External
interrupt
(8 channels)
Interrupt by edge detection (rising, falling, or both edges can be selected.)
Can be used to recover from standby modes.
Flash memory
Supports automatic programming, Embedded AlgorithmTM *4
Write/Erase/Erase-Suspend/Resume commands
A flag indicating completion of the algorithm
Number of write/erase cycles (Minimum) : 10000 times
Data retention time : 20 years
Erase can be performed on each block
Block protection with external programming voltage
Flash Security Feature for protecting the content of the Flash
(MB95F136MBS/F136NBS/F136JBS/F136MBW/F136NBW/F136JBW)
Standby mode Sleep, stop, watch (for dual clock product), and timebase timer
