鍙冩暩(sh霉)璩囨枡
| 鍨嬭櫉锛� | MB95F136JBWPF-GE1 |
| 寤犲晢锛� | Fujitsu Semiconductor America Inc |
| 鏂囦欢闋佹暩(sh霉)锛� | 19/64闋� |
| 鏂囦欢澶�?銆�?/td> | 0K |
| 鎻忚堪锛� | IC MCU 32KB FLASH 28SOP |
| 妯�(bi膩o)婧�(zh菙n)鍖呰锛� | 1 |
| 绯诲垪锛� | F²MC MB95130MB |
| 鏍稿績铏曠悊鍣細 | F²MC-8FX |
| 鑺珨灏哄锛� | 8-浣� |
| 閫熷害锛� | 16MHz |
| 閫ｉ€氭€э細 | LIN锛孲IO锛孶ART/USART |
| 澶栧湇瑷�(sh猫)鍌欙細 | LVD锛孭OR锛孭WM锛學DT |
| 杓稿叆/杓稿嚭鏁�(sh霉)锛� | 19 |
| 绋嬪簭瀛樺劜鍣ㄥ閲忥細 | 32KB锛�32K x 8锛� |
| 绋嬪簭瀛樺劜鍣ㄩ鍨嬶細 | 闁冨瓨 |
| RAM 瀹归噺锛� | 1K x 8 |
| 闆诲 - 闆绘簮 (Vcc/Vdd)锛� | 2.4 V ~ 5.5 V |
| 鏁�(sh霉)鎿�(j霉)杞�(zhu菐n)鎻涘櫒锛� | A/D 8x8/10b |
| 鎸暕鍣ㄥ瀷锛� | 澶栭儴 |
| 宸ヤ綔婧害锛� | -40°C ~ 105°C |
| 灏佽/澶栨锛� | 28-SOP |
| 鍖呰锛� | 绠′欢 |
| 鍏跺畠鍚嶇ū锛� | 865-1075 |
绗�1闋�绗�2闋�绗�3闋�绗�4闋�绗�5闋�绗�6闋�绗�7闋�绗�8闋�绗�9闋�绗�10闋�绗�11闋�绗�12闋�绗�13闋�绗�14闋�绗�15闋�绗�16闋�绗�17闋�绗�18闋�鐣�(d膩ng)鍓嶇19闋�绗�20闋�绗�21闋�绗�22闋�绗�23闋�绗�24闋�绗�25闋�绗�26闋�绗�27闋�绗�28闋�绗�29闋�绗�30闋�绗�31闋�绗�32闋�绗�33闋�绗�34闋�绗�35闋�绗�36闋�绗�37闋�绗�38闋�绗�39闋�绗�40闋�绗�41闋�绗�42闋�绗�43闋�绗�44闋�绗�45闋�绗�46闋�绗�47闋�绗�48闋�绗�49闋�绗�50闋�绗�51闋�绗�52闋�绗�53闋�绗�54闋�绗�55闋�绗�56闋�绗�57闋�绗�58闋�绗�59闋�绗�60闋�绗�61闋�绗�62闋�绗�63闋�绗�64闋�
MB95130MB Series
26
(Continued)
Address
Register
abbreviation
Register name
R/W
Initial value
0FA4H
PPGS
8/16-bit PPG start register
R/W
00000000B
0FA5H
REVC
8/16-bit PPG output inversion register
R/W
00000000B
0FA6H
to
0FA9H
(Disabled)
0FAAH
PDCRH0
16-bit PPG down counter register (Upper byte) ch.0
R
00000000B
0FABH
PDCRL0
16-bit PPG down counter register (Lower byte) ch.0
R
00000000B
0FACH
PCSRH0
16-bit PPG cycle setting buffer register (Upper byte) ch.0
R/W
11111111B
0FADH
PCSRL0
16-bit PPG cycle setting buffer register (Lower byte) ch.0
R/W
11111111B
0FAEH
PDUTH0
16-bit PPG duty setting buffer register (Upper byte) ch.0
R/W
11111111B
0FAFH
PDUTL0
16-bit PPG duty setting buffer register (Lower byte) ch.0
R/W
11111111B
0FB0H
to
0FBBH
(Disabled)
0FBCH
BGR1
LIN-UART baud rate generator register 1
R/W
00000000B
0FBDH
BGR0
LIN-UART baud rate generator register 0
R/W
00000000B
0FBEH
PSSR0
UART/SIO dedicated baud rate generator
prescaler selection register ch.0
R/W
00000000B
0FBFH
BRSR0
UART/SIO dedicated baud rate generator
baud rate setting register ch.0
R/W
00000000B
0FC0H
to
0FC2H
(Disabled)
0FC3H
AIDRL
A/D input disable register (Lower byte)
R/W
00000000B
0FC4H
to
0FE2H
(Disabled)
0FE3H
WCDR
Watch counter data register
R/W
00111111B
0FE4H
to
0FE6H
(Disabled)
0FE7H
ILSR2
Input level select register 2 (option)
R/W
00000000B
0FE8H,
0FE9H
(Disabled)
0FEAH
CSVCR
Clock supervisor control register
R/W
00011100B
0FEBH
to
0FEDH
(Disabled)
0FEEH
ILSR
Input level select register
R/W
00000000B
0FEFH
WICR
Interrupt pin control register
R/W
01000000B
0FF0H
to
0FFFH
(Disabled)
