SAL-XC866
Functional Description
PRELIMINARY
Data Sheet
25
V1.0, 2011-02
3.2.3
Bit Protection Scheme
The bit protection scheme prevents direct software writing of selected bits (i.e., protected
bits) using the PASSWD register. When the bit field MODE is 11B, writing 10011B to the
bit field PASS opens access to writing of all protected bits, and writing 10101B to the bit
field PASS closes access to writing of all protected bits. Note that access is opened for
maximum 32 CCLKs if the “close access” password is not written. If “open access”
password is written again before the end of 32 CCLK cycles, there will be a recount of
32 CCLK cycles. The protected bits include NDIV, WDTEN, PD, and SD.
PASSWD
Password Register
Reset Value: 07H
76
54
32
10
PASS
PROTECT
_S
MODE
wh
rh
rw
Field
Bits
Type Description
MODE
[1:0]
rw
Bit Protection Scheme Control bits
00
Scheme Disabled
11
Scheme Enabled (default)
Others: Scheme Enabled
These two bits cannot be written directly. To change
the value between 11B and 00B, the bit field PASS
must be written with 11000B; only then, will the
MODE[1:0] be registered.
PROTECT_S
2rh
Bit Protection Signal Status bit
This bit shows the status of the protection.
0
Software is able to write to all protected bits.
1
Software is unable to write to any protected
bits.
PASS
[7:3]
wh
Password bits
The Bit Protection Scheme only recognizes three
patterns.
11000B Enables writing of the bit field MODE.
10011B Opens access to writing of all protected bits.
10101B Closes access to writing of all protected bits.
