MB95R203
20
DS07-12625-4E
■ ELECTRICAL CHARACTERISTICS
1.
Absolute Maximum Ratings
(Continued)
Parameter
Symbol
Rating
Unit
Remarks
Min
Max
Power supply voltage*1
Vcc
Vss
0.3 Vss + 4.0
V
Input voltage*1
VI
Vss
0.3 Vss + 4.0
V
*2
Output voltage*1
VO
Vss
0.3 Vss + 4.0
V
*2
“L” level maximum output
current
IOL1
15
mA
Other than P05, P06, P62 and P63
IOL2
15
P05, P06, P62 and P63
“L” level average current
IOLAV1
4
mA
Other than P05, P06, P62 and P63
Average output current
=
operating current
× operating ratio
(1pin)
IOLAV2
12
P05, P06, P62 and P63
Average output current
=
operating current
× operating ratio
(1pin)
“L” level total maximum output
current
ΣIOL
100
mA
“L” level total average output
current
ΣIOLAV
50
mA
Total average output current
=
operating current
× operating ratio
(Total of pins)
“H” level maximum output
current
IOH1
15
mA
Other than P05, P06, P62 and P63
IOH2
15
P05, P06, P62 and P63
“H” level average current
IOHAV1
4
mA
Other than P05, P06, P62 and P63
Average output current
=
operating current
× operating ratio
(1 pin)
IOHAV2
8
P05, P06, P62 and P63
Average output current
=
operating current
× operating ratio
(1pin)
“H” level total maximum output
current
ΣIOH
100
mA
“H” level total average output
current
ΣIOHAV
50
mA
Total average output current
=
operating current
× operating ratio
(Total of pins)
Power consumption
Pd
320
mW
Operating temperature
TA
20
+ 70
°C
Storage temperature
Tstg
20
+ 85
°C
