參數資料
型號： SAA7120H
廠商： NXP SEMICONDUCTORS
元件分類： 顏色信號轉換
英文描述： Digital video encoder
中文描述： COLOR SIGNAL ENCODER, PQFP44
封裝： 10 X 10 MM, 1.75 MM HEIGHT, PLASTIC, SOT-307-2, QFP-44
文件頁數： 20/36頁
文件大?。?/td> 165K
代理商： SAA7120H
2002 Oct 11
20
Philips Semiconductors
Product specification
Digital video encoder
SAA7120H; SAA7121H
Table 34
Subaddress 75H
Table 35
Subaddresses 76H, 77H and 7CH
Table 36
Table 37
Subaddresses 7AH to 7CH
Table 38
Subaddress 7CH
DATA BYTE
DESCRIPTION
REMARKS
VS_S
vertical sync shift between RCV1 and RCV2 (switched to
output); in master mode it is possible to shift Hsync (RCV2;
CBLF = 0) against Vsync (RCV1; SRCV1 = 00)
standard value: VS_S = 3
DATA BYTE
DESCRIPTION
REMARKS
TTXOVS
first line of occurrence of signal on pin TTXRQ in odd field
line = (TTXOVS + 4) for M-systems
line = (TTXOVS + 1) for other systems
last line of occurrence of signal on pin TTXRQ in odd field
line = (TTXOVE + 3) for M-systems
line = TTXOVE for other systems
PAL: TTXOVS = 05H;
NTSC: TTXOVS = 06H
TTXOVE
PAL: TTXOVE = 16H;
NTSC: TTXOVE = 10H
DATA BYTE
DESCRIPTION
REMARKS
TTXEVS
first line of occurrence of signal on pin TTXRQ in even field
line = (TTXEVS + 4) for M-systems
line = (TTXEVS + 1) for other systems
last line of occurrence of signal on pin TTXRQ in even field
line = (TTXEVE + 3) for M-systems
line = TTXEVE for other systems
PAL: TTXEVS = 04H;
NTSC: TTXEVS = 05H
TTXEVE
PAL: TTXEVE = 16H;
NTSC: TTXEVE = 10H
DATA BYTE
DESCRIPTION
FAL
first active line: measured in lines; FAL = 0 coincides with the first field synchronization pulse
first active line = (FAL + 4) for M systems
first active line = (FAL + 1) for other systems
last active line: measured in lines; LAL = 0 coincides with the first field synchronization pulse
last active line = (LAL + 3) for M-systems
last active line = LAL for other systems
LAL
DATA BYTE
LOGIC LEVEL
DESCRIPTION
TTX60
0
1
enables NABTS (FISE = 1) or European TTX (FISE = 0); default after reset
enables world standard teletext 60 Hz (FISE = 1)
