Philips Semiconductors
PSMN004-60P/60B
N-channel enhancement mode field-effect transistor
Product data
Rev. 01 — 26 April 2002
4 of 13
9397 750 09156
Koninklijke Philips Electronics N.V. 2002. All rights reserved.
7.
Thermal characteristics
7.1 Transient thermal impedance
Table 4:
Symbol Parameter
R
th(j-mb)
thermal resistance from junction to mounting base
Figure 4
R
th(j-a)
thermal resistance from junction to ambient
SOT78
SOT404
Thermal characteristics
Conditions
Min Typ Max Unit
-
-
0.65 K/W
vertical in still air
mounted on a printed circuit board;
minimum footprint
-
-
-
-
60
50
K/W
K/W
Fig 4.
Transient thermal impedance from junction to mounting base as a function of pulse duration.
03af48
10-3
10-2
10-1
1
10-6
10-5
10-4
10-3
10-2
10-1
1
10
t
p
(s)
Z
th(j-mb)
(K/W)
single pulse
δ
= 0.5
0.2
0.1
0.05
0.02
tp
tp
T
T
P
t
δ
=
