BPV10
Vishay Telefunken
1 (5)
Rev. 3, 20-May-99
www.vishay.de
FaxBack +1-408-970-5600
Document Number 81502
Silicon PIN Photodiode
Description
BPV10 is a very high speed and high sensitive PIN
photodiode in a standard T–1 plastic package.
Due to its waterclear epoxy the device is sensitive to
visible and infrared radiation.
Features
Extra fast response times
High bandwidth B = 250 MHz at V
R
=12 V
High photo sensitivity
Radiant sensitive area A=0.78mm
2
Standard T–1 ( 5 mm) package with clear lens
Angle of half sensitivity
=
±
20
94 8390
Applications
Wide band detector for demodulation of fast signals, industrial electronics, measurement, control circuits and
fast interrupters
Absolute Maximum Ratings
T
amb
= 25 C
Parameter
Reverse Voltage
Power Dissipation
Junction Temperature
Storage Temperature Range
Soldering Temperature
Thermal Resistance Junction/Ambient
Test Conditions
Symbol
V
R
P
V
T
j
T
stg
T
sd
R
thJA
Value
60
215
100
–55...+100
260
350
Unit
V
mW
C
C
C
K/W
T
amb
25 C
t
5 s, 2 mm from body
