IDT5P49EE602
VERSACLOCK LOW POWER CLOCK GENERATOR
EEPROM CLOCK GENERATOR
IDT VERSACLOCK LOW POWER CLOCK GENERATOR
6
IDT5P49EE602
REV L 072512
SPREAD SPECTRUM GENERATION
(PLLB)
PLLB has spread spectrum generation capability, which
users have the option of turning on and off. Spread
spectrum profile, frequency, and spread are fully
programmable (within limits). The programmable spread
spectrum generation parameters are NC[10:0], MOD[12:0],
and NSS[10:0] bits. To enable spread spectrum, set
SSENB_B=0.
The spread spectrum circuitry was specifically developed to
accommodate video display applications. The spread
modulation frequency can be defined to exactly equal the
horizontal line frequency (HSYNC)
NC[10:0]
These bits are used to determine the number of pulses per
spread spectrum cycle. For video applications, NC is the
number of pixels on the horizontal display row (or integer
multiple of displayed pixels in a row). By matching the
spread period to the screen, no tearing or “shimmer” will be
apparent.
NC must be an even number to insure that the upward
spread transition has the same number of steps as the
downward spread transition.
For non-video applications, this can also be seen as the
number of clock cycles for a complete spread spectrum
period.
MOD[12:0]
These bits relate the reference frequency to the target
average spread output frequency (FMID). FMID is the
midpoint between FMAX (maximum frequency) and FMIN
(minimum frequency).
FMID = (FMAX + FMIN) / 2
MOD = (FREF * NC) / (2 * FMID)
NSS[10:0]
These bits control the amplitude of the spread modulation.
NSS = (NC / 2) + (NC / 8) * (FMAX - FMIN) / FMID
Modulation frequency:
FMOD = FMID / NC (Eq. 11)
Video Example
FREF = 25MHz, FOUT = 27 MHz, 640 pixels per line, center
spread of ±1%. Find the necessary spread spectrum
register settings.
FMID = FOUT
NC = 640 or 320 or 160 (integer number of spread
periods/screen)
MOD = (25MHz * 640)/(2 * 27MHz) = 296
NSS = (640/2)+(640/8)*(27.27MHz-26.73MHz)/27MHz =
322.
FMOD = 27MHz/640 = 42.2kHz.
Non-Video Example
FREF = 25MHz, FOUT = 27 MHz, 32kHz modulation rate,
center spread of ±1%. Find the necessary spread spectrum
register settings.
FMID = FOUT
FMOD = 32kHz = 27MHz/NC.
NC = 844
MOD = (25MHz * 844)/(2 * 27MHz) = 391
NSS = (844/2)+(844/8)*(27.27MHz-26.73MHz)/27MHz =
424.
