UM000500-Z8X1098
4–1
Z8ICE000ZEM U
SER
’
S
M
ANUAL
C
HAPTER
4
T
ROUBLESHOOTING
G
UIDE
INTRODUCTION
Before contacting your ZiLOG representative or submitting a Problem Report, please follow these simple
steps. Also, check the Precautions and Limitations sections in the Data Sheet included with your emulator to
eliminate other possible known problems. If a hardware failure is suspected, contact your local ZiLOG repre-
sentative for assistance.
INITIAL SCREEN DOES NOT APPEAR
The initial ZiLOG screen does not appear after selecting a COM port, and a message is displayed that begins
“Time-out while reading...”
1.
Check the RS-232 cable connection or try another cable that is known to be good.
2.
Check if transmit/receive signals need to be swapped.
NOTE:
On some DB9 connectors for the COM ports, the transmit/receive signal may be swapped and a
Null Modem adapter may be required.
3.
Verify that the power supply is connected and turned ON, and that power is available.
4.
Verify that the power supply is set at the correct voltage.
5.
Check that the power supply can supply the required 0.5 Amp current to the emulator.
6.
Check selected port using another application or select another COM port.
7.
After resetting the emulator, wait 5 seconds (minimum) before running the GUI software.
