Page 0 / Register 53 (0x35): DOUT (OUT Pin) Control
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D5
R/W
000
Reserved
D4
R/W
1
0: DOUT bus keeper enabled
1: DOUT bus keeper disabled
D3–D1
R/W
001
000: DOUT disabled (output buffer powered down)
001: DOUT = primary DOUT output for codec interface
010: DOUT = general-purpose output
011: DOUT = CLKOUT output
100: DOUT = INT1 output
101: DOUT = INT2 output
110: DOUT = secondary BCLK output for codec interface
111: DOUT = secondary WCLK output for codec interface
D0
R/W
0
0: DOUT general-purpose output value = 0
1: DOUT general-purpose output value = 1
Page 0 / Register 54 (0x36): DIN (IN Pin) Control
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D3
R/W
0000 0
Reserved
D2–D1
R/W
01
00: DIN disabled (input buffer powered down)
01: DIN enabled (can be used as DIN for codec interface, Dig_Mic_In or in ClockGen block)
10: DIN is used as general-purpose input (GPI)
11: Reserved
D0
R
X
DIN input-buffer value
Page 0 / Register 55–59 : Reserved
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D0
R
XXXX XXXX
Reserved. Do not write to these registers.
Page 0 / Register 60 (0x3C): DAC Processing Blocks Selection
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D5
R/W
000
Reserved. Write only default value.
D4–D0
R/W
0 0001
0 0000: Reserved. Write only reset value.
0 0001: DAC signal-processing block PRB_P1
0 0010: DAC signal-processing block PRB_P2
0 0011: DAC signal-processing block PRB_P3
0 0100: DAC signal-processing block PRB_P4
...
1 1000: DAC signal-processing block PRB_P24
1 1001: DAC signal-processing block PRB_P25
1 1010–1 1111: Reserved. Do not use.
Copyright 2009, Texas Instruments Incorporated
REGISTER MAP
91
Product Folder Link(s): TLV320AIC3110
