XE169FH
XC2000 Family Derivatives / High Line
Electrical Parameters
Data Sheet
101
V1.2, 2010-09
Active Mode Power Supply Current
The actual power supply current in active mode not only depends on the system
frequency but also on the configuration of the XE169xH’s subsystem.
Besides the power consumed by the device logic the power supply pins also provide the
current that flows through the pin output drivers.
A small current is consumed because the drivers’ input stages are switched.
The IO power domains can be supplied separately. Power domain A (
V
DDPA) supplies the
A/D converters and Port 6. Power domain B (
V
DDPB) supplies the on-chip EVVRs and all
other ports.
During operation domain A draws a maximum current of 1.5 mA for each active A/D
converter module from
V
DDPA.
In Fast Startup Mode (with the Flash modules deactivated), the typical current is reduced
to 3 + 0.6
×f
SYS mA.
Table 16
Switching Power Consumption
Parameter
Symbol
Values
Unit
Note /
Test Condition
Min.
Typ.
Max.
Power supply current
(active) with all peripherals
active and EVVRs on
I
SACT
CC
25 +
0.9 x
f
SYS
1)
f
SYS in MHz
25 +
1.4 x
f
mA
power_mode=
active ;
voltage_range=
both
2)3)4)
2) The pad supply voltage pins (
V
DDPB) provide the input current for the on-chip EVVRs and the current
consumed by the pin output drivers. A small current is consumed because the drivers input stages are
switched. In Fast Startup Mode (with the Flash modules deactivated), the typical current is reduced to 3 + 0.6
x
f
SYS.
3) Please consider the additional conditions described in section "Active Mode Power Supply Current".
4) The pad supply voltage has only a minor influence on this parameter.
Power supply current in
stopover mode, EVVRs on
I
SSO CC
1.4
4.0
mA
power_mode=
stopover ;
voltage_range=
both
