Semiconductor Components Industries, LLC, 2006
March, 2006
Rev. 2
1
Publication Order Number:
N
TP2955/D
NTP2955
Power MOSFET
60 V,
12 A, Single P
Channel, TO
220
Features
Low R
DS(on)
Rugged Performance
Fast Switching
Pb
Free Package is Available*
Applications
Industrial
Automotive
Power Supplies
MAXIMUM RATINGS
(T
J
= 25
°
C unless otherwise noted)
Parameter
Symbol
Value
Unit
Drain
to
Source Voltage
V
DSS
60
V
Gate
to
Source Voltage
V
GS
±
20
V
Continuous Drain
Current (Note 1)
Steady
State
T
C
= 25
°
C
T
C
= 85
°
C
T
C
= 25
°
C
I
D
12
A
9.0
Power Dissipation
(Note 1)
P
D
62.5
W
Continuous Drain
Current (Note 1)
Steady
State
T
A
= 25
°
C
T
A
= 85
°
C
T
A
= 25
°
C
I
D
2.4
A
1.8
Power Dissipation
(Note 1)
P
D
2.4
W
Pulsed Drain Current
t
p
= 10 s
I
DM
42
A
Operating Junction and Storage Temperature
T
J
,
T
STG
55 to
175
°
C
Source Current (Body Diode)
I
S
12
A
Single Pulse Drain
to
Source Avalanche
Energy (V
DD
=
30 V, V
G
=
10 V,
I
PK
=
12 A, L = 3.0 mH, R
G
= 3.0 )
EAS
216
mJ
Lead Temperature for Soldering Purposes
(1/8” from case for 10 s)
T
L
260
°
C
THERMAL RESISTANCE RATINGS
Parameter
Symbol
Max
Unit
Junction
to
Case
R
JC
2.4
°
C/W
Junction
to
Ambient
Steady State (Note 1)
R
JA
62.5
Stresses exceeding Maximum Ratings may damage the device. Maximum
Ratings are stress ratings only. Functional operation above the Recommended
Operating Conditions is not implied. Extended exposure to stresses above the
Recommended Operating Conditions may affect device reliability.
1. When surface mounted to an FR4 board using 1 in pad size
(Cu. area = 1.127 in sq [1 oz] including traces).
*For additional information on our Pb
Free strategy and soldering details, please
download the ON Semiconductor Soldering and Mounting Techniques
Reference Manual, SOLDERRM/D.
D
S
G
P
Channel
60 V
156 m @
10 V
R
DS(on)
Typ
12 A
I
D
MAX
V
(BR)DSS
Device
Package
Shipping
ORDERING INFORMATION
NTP2955
TO
220
50 Units / Rail
TO
220
CASE 221A
STYLE 5
123
A
Y
WW
G
= Assembly Location
= Year
= Work Week
= Pb
Free Package
NTP2955G
TO
220
(Pb
Free)
50 Units / Rail
http://onsemi.com
NT2955G
AYWW
D S
D
G
1
MARKING DIAGRAM &
PIN ASSIGNMENT
