Preliminary Data Sheet M15855EJ3V0DS
14
MC-22212361-X
Electrical Specifications
Before turning on power, input VSS
± 0.2 V to the /RESET pin until VCCf ≥ VCCf (MIN.) and keep that state for 200
s.
Absolute Maximum Ratings
Parameter
Symbol
Condition
Rating
Unit
Supply voltage
VCCf
with respect to VSS
–0.5 to +2.4
V
VCCs
–0.5
Note 1 to +3.3
Input / Output supply
VCCQf with respect to VSS
–0.5 to +4.0
V
voltage
Input / Output voltage
VT
with respect /WP(ACC), /RESET
–0.5
Note 2 to +13.0
V
to VSS
except /WP(ACC), /RESET
–0.5
Note 1 to VCCQf + 0.4 (3.3 V MAX.),
–0.5
Note 1 to VCCs + 0.4 (3.3 V MAX.)
Ambient operation
TA
–25 to +85
°C
temperature
Storage temperature
Tstg
–55 to +125
°C
Tbias
at bias
–25 to +85
Notes 1. –1.5 V (MIN.) (pulse width
≤ 30 ns)
2. –2.0 V (MIN.) (pulse width
≤ 20 ns)
Caution Exposing the device to stress above those listed in Absolute Maximum Rating could cause
permanent damage. The device is not meant to be operated under conditions outside the limits
described in the operational section of this specification. Exposure to Absolute Maximum Rating
conditions for extended periods may affect device reliability.
Recommended Operating Conditions
Parameter
Symbol
Test condition
MIN.
TYP.
MAX.
Unit
Supply voltage
VCCf
-D80X
1.8
2.1
V
-E85X
1.65
1.95
VCCs2.7
3.1
Input / Output supply voltage
VCCQf
2.7
3.1
V
High level input voltage
VIH
2.4
VCCQf +0.4,
V
VCCs +0.4
VID
High voltage is applied (/RESET)
9.0
11.0
V
Low level input voltage
VIL
–0.3
Note
+0.5
V
Accelerated programming voltage
VACC
High voltage is applied
8.5
9.5
V
Ambient operating temperature
TA
–25
+85
°C
Note –1.0 V (MIN.) (pulse width = 20 ns)
