MAX11043
4-Channel, 16-Bit, Simultaneous-Sampling ADCs
with PGA, Filter, and 8-/12-Bit Dual-Stage DAC
26
Maxim Integrated
C-RAM
ADDRESS
FLASH
ADDRESS
MSB FOR C-RAM
LSB FOR C-RAM
08h
—
Not used
04h
09h*
EQ filter coefficient -A3 for filter stage 1
—
0Ah*
—
EQ filter coefficient B3 and rectify bit for filter stage 1
05h
0Bh*
EQ filter coefficient B2 for filter stage 1
—
0Ch
—
EQ filter gain for filter stage 2
06h
0Dh
EQ filter coefficient -A2 for filter stage 2
—
0Eh
—
Not used
07h
0Fh
EQ filter coefficient -A3 for filter stage 2
—
10h
—
EQ filter coefficient B3 and rectify bit for filter stage 2
08h
11h
EQ filter coefficient B2 for filter stage 2
—
12h
—
EQ filter gain for filter stage 3
09h
13h
EQ filter coefficient -A2 for filter stage 3
—
14h
—
Not used
0Ah
15h
EQ filter coefficient -A3 for filter stage 3
—
16h
—
EQ filter coefficient B3 and rectify bit for filter stage 3
0Bh
17h
EQ filter coefficient B2 for filter stage 3
—
18h
—
EQ filter gain for filter stage 4
0Ch
19h
EQ filter coefficient -A2 for filter stage 4
—
1Ah
—
Not used
0Dh
1Bh
EQ filter coefficient -A3 for filter stage 4
—
1Ch
—
EQ filter coefficient B3 and rectify bit for filter stage 4
0Eh
1Dh
EQ filter coefficient B2 for filter stage 4
—
1Eh
—
EQ filter gain for filter stage 5
0Fh
1Fh
EQ filter coefficient -A2 for filter stage 5
—
20h
—
Not used
10h
21h
EQ filter coefficient -A3 for filter stage 5
—
22h
—
EQ filter coefficient B3 and rectify bit for filter stage 5
11h
23h
EQ filter coefficient B2 for filter stage 5
—
24h
—
EQ filter gain for filter stage 6
12h
25h
EQ filter coefficient -A2 for filter stage 6
—
26h
—
Not used
13h
27h
EQ filter coefficient -A3 for filter stage 6
—
28h
—
EQ filter coefficient B3 and rectify bit for filter stage 6
14h
29h
EQ filter coefficient B2 for filter stage 6
—
2Ah
—
EQ filter gain for filter stage 7
15h
2Bh
EQ filter coefficient -A2 for filter stage 7
—
2Ch
—
Not used
16h
2Dh
EQ filter coefficient -A3 for filter stage 7
—
Table 4. C-RAM and Flash Memory Map (continued)
