Rev.
No.
date
1.00
First Edition
970604
1.01
The following are added:
980526
MASK ROM ORDER CONFIRMATION FORM
MARK SPECIFICATION FORM
2.00
The following are revised:
980731
REVISION DESCRIPTION LIST
M37733MHBXXXFP Datasheet
(1)
Revision Description
Page
P5
Right column
Line 4
P5
Fig. 1
P9
Right column
Line 12
P63
Left column
Line 2
P63
Fig. 70
P64
Fig. 72
P65
Right column
Line 2
Previous Version
Additionally, the internal ROM area can be modi-
fied by software.
Note. Internal ROM area can be modified. (Refer
to the section on ROM area modification
function.)
The CPU operates on an internal clock
φ’s fre-
quency which is obtained by dividing the external
clock frequency f(XIN) by two.
The internal ROM size and its address area of the
M37733MHBXXXFP can be modified by the
memory allocation control register’s bits 0,1 and 2
shown in Figure 70.
Figure 72 shows the memory allocation in which
the internal ROM size and its address area are
modified.
Memory allocation selection bits
ROM size
(ROM area)
0 0 0 : 124 Kbytes
(addresses 00100016 – 01FFFF16)
0 0 1 : 120 Kbytes
(addresses 00200016 – 01FFFF16)
1 1 0 : 96 Kbytes
(addresses 00800016 – 01FFFF16)
1 1 1 : 32 Kbytes
(addresses 00800016 – 00FFFF16)
Refer to page (2).
The M37733MHBXXXFP has 28 powerful
addressing modes. Refer to the SINGLE-CHIP 16-
BIT MICROCOMPUTERS DATA BOOK for the
details of each addressing mode.
MACHINE INSTRUCTION LIST
The M37733MHBXXXFP has 103 machine
instructions. Refer to the SINGLE-CHIP 16-BIT
MICROCOMPUTERS DATA BOOK for details.
Revised Version
Additionally, the internal ROM and RAM area can
be modified by software.
Note. Internal ROM and RAM area can be modi-
fied. (Refer to the section on ROM area
modification function.)
The CPU operates on an internal clock
φ’s fre-
quency.
The internal ROM size and RAM size of the
M37733MHBXXXFP can be modified by the
memory allocation control register’s bits 0,1 and 2
shown in Figure 70.
Figure 72 shows the memory allocation in which
the internal ROM size and RAM size are modified.
Memory allocation selection bits
ROM size
RAM size
0 0 0 : 124 Kbytes
3968 bytes
0 0 1 : 120 Kbytes
3968 bytes
0 1 0 : 60 Kbytes
2048 bytes
1 0 0 : 32 Kbytes
2048 bytes
1 0 1 : 16 Kbytes
2048 bytes
1 1 0 : 96 Kbytes
3968 bytes
Refer to page (3).
The M37733MHBXXXFP has 28 powerful
addressing modes. Refer to the “7700 Family
Software Manual” for the details.
MACHINE INSTRUCTION LIST
The M37733MHBXXXFP has 103 machine
instructions. Refer to the “7700 Family Software
Manual” for the details.
