L6917
22/27
Figure 16. PCB and Components Layouts
Design Example.
s
Output Voltage (nominal) 1.700V
s
Output Current (nominal) 45A
s
Static tolerance
+100mV; -50mV
Considering the high slope for the load transient, a high switching frequency has to be used. In addition to fast
reaction, this helps in reducing output and input capacitor. Inductance value is also reduced.
A switching frequency of 300kHz for each phase is then considered allowing large bandwidth for the compen-
sation network.
s
Current Reading Network and Over Current:
Since the maximum output current is 45A, the over current threshold has to be set at 140% of the
maximum nominal current, the over-current threshold has then to be set at 31.5A. Considering to sense
the output current across the low-side mosfet RdsON, STB90NF03L has 6.5m
max at 25° that
becomes 9.1m
considering the temperature variation (+40%); the resulting transconductance resistor
Rg has to be:
(R3 to R6)
s
Droop function Design:
Considering a voltage drop of 100mV at full load, the feedback resistor RFB has to be
(R7)
voltage drop at OCP threshold results in 140mV.
Internal SGND Plane
Solder Side
Rg
I
MA X
RdsON
35
-------------------------------------- -
31.5 9.1m
35
------------------------------
8.2k
==
=
R
FB
100mV
50
A
-------------------
2k
==
