CE Pin
To change the counter controlling the output voltage, the CE
(Counter Enable) pin must be pulled high (VDD). When the CE pin
is pulled low, the counter value is loaded from EEPROM, which
takes 10ms (during which the inputs should remain constant).
The CE pin has an internal pull-down to keep it at a logic low
when not being driven. CE should be pulled low before powering
the device down to ensure that any glitches or transients during
power-down will not cause unwanted EEPROM overwriting.
The CE pin has a Schmitt trigger on the input to prevent false
triggering during slow transitions of the CE pin. The CE pin
transition time should be 10s or less.
Programming the EEPROM
To program the non-volatile EEPROM, pull the CTL pin above 4.9V
for more than 200s. The level and timing is shown in Figure
9. It
then takes a maximum of 100ms after CTL crosses 4.9V for the
programming to be completed inside the device.
When the part is programmed, the data in the counter register is
written into the EEPROM. This value will be loaded from the
EEPROM during subsequent power-ups as well as when the CE
pin is pulled low. The ISL24212 is factory-programmed to
mid-scale. As with asserting CE, the first pulse after a program
operation is ignored. The EEPROM contents can be written and
verified using the following steps:
1. Power-up the ISL24212. The EEPROM value will be loaded.
2. Set the CE pin to VDD.
3. Change the VOUT voltage using the CTL pin to the desired
value, noting that first pulse will be ignored.
4. Pull the CTL pin to 4.9V or higher for at least 200s. The
counter value will be written to EEPROM after 100ms.
5. Change the VOUT value (using the CTL pin) to a different value,
noting that first pulse after programming will be ignored.
6. Set the CE pin to 0V. The stored output value will be loaded
from EEPROM after 10ms.
7. Verify that the output value is the same value programmed in
Step 4.
The CTL pin should be left floating after programming. The
voltage at the CTL pin will be internally biased to VDD/2 to ensure
that no additional pulses will be seen by the Up/Down counter. To
prevent further changes, ground the CE pin.
Typical Application Circuit
Shown below in Figure
10 is a typical circuit that can be used to
program the ISL24212 via the up/down counter interface. Three
momentary push-button switches are required. SW1 connected
between CTL and AVDD allows the user to bring CTL above VDD for
programming the EEPROM, SW2 connected to VDD to pull CTL up,
and SW3 connected to GND to pull CTL to down. All the switches
should have 1kΩ current-limiting resistors in series.
For adjustment and programming to occur, the CE pin has to be
set to VDD. This can be achieved by a single-pull double-throw
switch (SW4) connected between VDD and GND.
Note that pressing the UP button increments the counter, but
results in VCOM_OUT decreasing. Similarly, pressing the DOWN
button decrements the counter, and results in VCOM_OUT
increasing.
