| 型號： | HSP45116AVC-52Z |
| 廠商： | Intersil |
| 文件頁數： | 7/19頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC OSC NCO 52MHZ 160-MQFP |
| 標準包裝： | 24 |
| 類型： | 數控振蕩器（NCO） |
| 頻率： | 52MHz |
| 電源電壓： | 4.75 V ~ 5.25 V |
| 電流 - 電源： | 184mA |
| 工作溫度： | 0°C ~ 70°C |
| 封裝/外殼： | 160-BQFP |
| 包裝： | 托盤 |
| 供應商設備封裝： | 160-MQFP（28x28） |
| 安裝類型： | 表面貼裝 |
Absolute Maximum Ratings
Thermal Information
Supply Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +7.0V
Input, Output or I/O Voltage Applied . . . . . GND -0.5V to VCC +0.5V
ESD Classification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Class 1
Operating Conditions
Voltage Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . +4.75V to +5.25V
Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . 0°C to +70°C
Thermal Resistance (Typical, Note 1)
θJA (°C/W)
MQFP Package . . . . . . . . . . . . . . . . . . . . . . . . . . . .
38.0
Maximum Junction Temperature . . . . . . . . . . . . . . . . . . . . . . +150°C
Maximum Storage Temperature Range . . . . . . . . . . -65°C to +150°C
Pb-free reflow profile . . . . . . . . . . . . . . . . . . . . . . . . . .see link below
Die Characteristics
Gate Count . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26,000 Gates
CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.
NOTE:
1.
θ
JA is measured with the component mounted on an evaluation PC board in free air.
15
FN4156.4
May 7, 2007
DC Electrical Specifications
VCC = 5.0V ±5%, TA = 0°C to +70°C
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
MAX
UNITS
Power Supply Current
ICCOP
VCC = Max, CLK Frequency 52.6MHz
Notes 2, 3
-
184
mA
Standby Power Supply Current
ICCSB
VCC = Max, Outputs Not Loaded
-
500
μA
Input Leakage Current
II
VCC = Max, Input = 0V or VCC
-10
10
μA
Output Leakage Current
IO
VCC = Max, Input = 0V or VCC
-10
10
μA
Logical One Input Voltage
VIH
VCC = Max
2.0
-
V
Logical Zero Input Voltage
VIL
VCC = Min
-
0.8
V
Logical One Input Voltage: CLK
VIHC
VCC = Max
3.0
-
V
Logical One Output Voltage
VOH
IOH = -5mA, VCC = Min
2.6
-
V
Logical Zero Output Voltage
VOL
IOL = 5mA, VCC = Min
-
0.4
V
Input Capacitance
CIN
CLK Frequency 1MHz
All measurements referenced to GND.
-
10
pF
Output Capacitance
COUT
-
10
pF
NOTES:
2. Power supply current is proportional to frequency. Typical rating is 3.5mA/MHz.
3. Output load per test circuit and CL = 40pF.
4. Not tested, but characterized at initial design and at major process/design changes.
AC Electrical Specifications
PARAMETER
SYMBOL
NOTES
52.6MHz (-52)
UNITS
MIN
MAX
CLK Period
tCP
19
-
ns
CLK High
tCH
7
-
ns
CLK Low
tCL
7
-
ns
WR Low
tWL
7
-
ns
WR High
tWH
7
-
ns
Setup Time AD0-1, CS to WR
tAWS
10
-
ns
Hold Time AD0-1, CS from WR
tAWH
0
-
ns
Setup Time C0-15 to WR
tCWS
10
-
ns
Hold Time C0-15 from WR
tCWH
0
-
ns
HSP45116A
