| 型號： | HI3-DAC80V-5 |
| 廠商： | Intersil |
| 文件頁數： | 3/8頁 |
| 文件大?。?/td> | 0K |
| 描述： | CONV D/A 12BIT OUTPUT AMP 24PDIP |
| 標準包裝： | 15 |
| 設置時間： | 1.5µs |
| 位數： | 12 |
| 數據接口： | 并聯 |
| 轉換器數目： | 1 |
| 電壓電源： | 雙 ± |
| 工作溫度： | 0°C ~ 75°C |
| 安裝類型： | 通孔 |
| 封裝/外殼： | 24-DIP（0.600"，15.24mm） |
| 供應商設備封裝： | 24-PDIP |
| 包裝： | 管件 |
| 輸出數目和類型： | 1 電壓，單極；1 電壓，雙極 |
| 采樣率（每秒）： | 667k |
3
Absolute Maximum Ratings
Thermal Information
Power Supply Inputs
+VS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +20V
-VS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -20V
Reference
Input (Pin 16) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +VS
Output Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.5mA
Digital Inputs (Bits 1 to 12). . . . . . . . . . . . . . . . . . . . . . . . -1V to +VS
Operating Conditions
Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0oC to 75oC
Thermal Resistance (Typical, Note 1)
θJA (oC/W)
PDIP Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
55
Maximum Power Dissipation
PDIP Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 550mW
Maximum Junction Temperature . . . . . . . . . . . . . . . . . . . . . . 150oC
Maximum Storage Temperature Range . . . . . . . . . . -65oC to 150oC
Maximum Lead Temperature (Soldering 10s) . . . . . . . . . . . . 300oC
Die Characteristics
Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Bipolar-DI
Transistor Count. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214
CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the
device at these or any other conditions above those indicated in the operational sections of this specication is not implied.
NOTE:
1.
θJA is measured with the component mounted on a low effective thermal conductivity test board in free air. See Tech Brief TB379 for details.
Electrical Specications
TA = 25
oC, V
S ±12V to ±15V (Note 5), Pin 16 Shorted to Pin 24, Unless Otherwise Specied
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNITS
SYSTEM PERFORMANCE
Resolution
-
12
Bits
ACCURACY (Note 3)
Linear Error
Full Temperature
-
±1/4
±1/2
LSB
Differential Linearity Error
Full Temperature
-
±1/2
±3/4
LSB
Monotonicity
Full Temperature
Guaranteed
Gain Error
Full Temperature (Notes 2, 4)
-
±0.1
±0.3
% FSR
Offset Error
Full Temperature (Note 2)
±0.05
±0.15
% FSR
ANALOG OUTPUT
Output Ranges (See Figure 2 and
Table 2)
-
±2.5
-
V
-
±5-
V
-
±10
-
V
-
0 to 5
-
V
-
0 to 10
-
V
Output Current
±5-
-
mA
Output Resistance
-
0.05
-
Short Circuit Duration
To Common
Continuous
-
DRIFT (Note 3)
Total Bipolar Drift (Includes Gain,
Offset and Linearity Drifts)
Full Temperature
-
±20
ppm/oC
Total Error
Unipolar
Full Temperature (Note 6)
-
±0.08
±0.15
% FSR
Bipolar
Full Temperature (Note 6)
-
±0.06
±0.1
% FSR
Gain
With Internal Reference
-
±15
±30
ppm/oC
Without Internal Reference
-
±7
-
ppm/oC
HI-DAC80V
