TB6615PG
2007-08-01
9
Application Circuit Example 3
1-2-phase excitation system for a two-phase motor,Ⅰ
·
When an inductive kick of the motor is large, the snubber diodes should be placed across the coil to suppress the
inductive kick. (This also applies to Application Circuit Example 4.)
Application Circuit Example 4
1-2-phase excitation system for a two-phase motor,Ⅱ
Note: The IC may be destroyed in case of a short-circuit across outputs, a short-circuit to power supply or a short-circuit
to ground. This possibility should be fully considered in the design of the output, VCC (VM, VS and VEE) and ground
lines.
TB6615PG
Stepping motor
