Semiconductor Group
1
NPN Silicon AF Transistor
SMBTA 20
5.91
Maximum Ratings
Type
Ordering Code
(tape and reel)
Q6800-A6477
Marking
Package
1)
Pin Configuration
1
2
SMBTA 20
s1C
SOT-23
B
E
C
3
Parameter
Collector-emitter voltage
Emitter-base voltage
Symbol
Values
40
4
Unit
V
V
CE0
Collector current
Peak collector current
Peak base current
I
C
100
200
200
mA
Total power dissipation,
T
S
= 71C
Junction temperature
Storage temperature range
P
tot
330
150
– 65 … + 150
mW
C
T
j
T
stg
Thermal Resistance
Junction - ambient
2)
Junction - soldering point
R
th JA
≤
310
K/W
R
th JS
≤
240
V
EB0
I
CM
I
BM
1)
For detailed information see chapter Package Outlines.
2)
Package mounted on epoxy pcb 40 mm
×
40 mm
×
1.5 mm/6 cm
2
Cu.
G
High DC current gain
G
Low collector-emitter saturation voltage
