參數資料
| 型號： | SC427MLTRT |
| 廠商： | Semtech |
| 文件頁數： | 28/33頁 |
| 文件大?。?/td> | 894K |
| 描述： | IC REG DL BUCK/LINEAR 32MLPQ |
| 標準包裝： | 1 |
| 系列： | EcoSpeed®, SmartDrive™ |
| 拓?fù)洌?/td> | 降壓（降壓）（1），線性（LDO）（1） |
| 功能： | 任何功能 |
| 輸出數： | 2 |
| 頻率 - 開關： | 1MHz |
| 電壓/電流 - 輸出 1： | 可調，10A |
| 電壓/電流 - 輸出 2： | 5V，200mA |
| 帶 LED 驅動器： | 無 |
| 帶監控器： | 無 |
| 帶序列發生器： | 無 |
| 電源電壓： | 3 V ~ 28 V |
| 工作溫度： | -40°C ~ 85°C |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 32-VFQFN 裸露焊盤 |
| 供應商設備封裝： | 32-MLPQ（5x5） |
| 包裝： | 標準包裝 |
| 其它名稱： | SC427MLDKR |
第1頁第2頁第3頁第4頁第5頁第6頁第7頁第8頁第9頁第10頁第11頁第12頁第13頁第14頁第15頁第16頁第17頁第18頁第19頁第20頁第21頁第22頁第23頁第24頁第25頁第26頁第27頁當前第28頁第29頁第30頁第31頁第32頁第33頁
SC417/SC427
28
Applications Information (continued)
To compensate for valley regulation, it may be desirable to
use passive droop. Take the feedback directly from the
output side of the inductor and place a small amount of
trace resistance between the inductor and output capaci-
tor. This trace resistance should be optimized so that at
full load the output droops to near the lower regulation
limit. Passive droop minimizes the required output capaci-
tance because the voltage excursions due to load steps
are reduced as seen at the load.
The use of 1% feedback resistors may result in up to 1%
error. If tighter DC accuracy is required, 0.1% resistors
should be used.
The output inductor value may change with current. This
will change the output ripple and therefore will have a
minor effect on the DC output voltage. The output ESR
also affects the output ripple and thus has a minor effect
on the DC output voltage.
Switching Frequency Variations
The switching frequency will vary depending on line and
load conditions. The line variations are a result of fixed
propagation delays in the on-time one-shot, as well as
unavoidable delays in the external MOSFET switching. As
V
IN
increases, these factors make the actual DH on-time
slightly longer than the ideal on-time. The net effect is
that frequency tends to falls slightly with increasing input
voltage.
The switching frequency also varies with load current as a
result of the power losses in the MOSFETs and the induc-
tor. For a conventional PWM constant-frequency con-
verter, as load increases the duty cycle also increases
slightly to compensate for IR and switching losses in the
MOSFETs and inductor. A constant on-time converter
must also compensate for the same losses by increasing
the effective duty cycle (more time is spent drawing
energy from V
IN
as losses increase). The on-time is essen-
tially constant for a given V
OUT
/V
IN
combination, to offset
the losses the off-time will tend to reduce slightly as load
increases. The net effect is that switching frequency
increases slightly with increasing load.
