參數資料
| 型號： | PI6C410MAE |
| 廠商： | Pericom |
| 文件頁數： | 19/21頁 |
| 文件大小： | 0K |
| 描述： | IC CLK GEN INTEL PCI-EX 56-TSSOP |
| 產品變化通告： | Product Discontinuation Notice 11/Feb/2008 |
| 標準包裝： | 35 |
| 系列： | PCI Express® (PCIe) |
| 類型： | 時鐘/頻率發生器，多路復用器 |
| PLL： | 是 |
| 主要目的： | Intel CPU，PCI Express（PCIe） |
| 輸入： | 晶體 |
| 輸出： | 時鐘 |
| 電路數： | 1 |
| 比率 - 輸入:輸出： | 1:19 |
| 差分 - 輸入:輸出： | 無/是 |
| 頻率 - 最大： | 400MHz |
| 電源電壓： | 3.135 V ~ 3.465 V |
| 工作溫度： | 0°C ~ 70°C |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 56-TFSOP（0.240"，6.10mm 寬） |
| 供應商設備封裝： | 56-TSSOP |
| 包裝： | 管件 |
7
PS8736F
11/12/08
PI6C410M/410MA
Clock Generator for Intel
PCI Express Mobile Chipset
Data Byte 4: Control Register
Bit
Descriptions
Type
Power Up
Condition
Output(s) Affected
Pin
Source
Pin
0
CPU_0 Output Control
0 = Free Running,
1 = Stopped with CPU_STOP#
RW
1 = Stopped with
CPU_STOP#
assertion
CPU_0
43, 44
NA
1
CPU_1 Output Control
0 = Free Running,
1 = Stopped with CPU_STOP#
RW
1 = Stopped with
CPU_STOP#
assertion
CPU_1
40, 41
NA
2
CPU_2 Output Control
0 = Free Running,
1 = Stopped with CPU_STOP#
RW
1 = Stopped with
CPU_STOP#
assertion
CPU_2
35, 36
NA
3
PCIF_0 Output Control
0 = Free Running,
1 = Stopped with PCI_STOP#
RW
0 = Free running,
not affected by
PCI_STOP#
PCIF_0
8
NA
4
PCIF_1 Output Control
0 = Free Running,
1 = Stopped with PCI_STOP#
RW
0 = Free running,
not affected by
PCI_STOP#
PCIF_1
9
NA
5
Reserved
RW
6
DOT_Pwrdwn drive mode
1 = Hi-Z, 0 = Driven in Pwrdwn
RW
0 = Driven in
power down
DOT_96 &
DOT_96#
14, 15
NA
7
Reserved
RW
Data Byte 5: Control Register
Bit
Descriptions
Type
Power Up
Condition
Output(s) Affected
Pin
Source
Pin
0
CPU_0 Pwrdwn drive mode
1 = Hi-Z, 0 = Driven in Pwrdwn
RW
0 = Driven in
power down
CPU_0 & CPU_0#
43, 44
NA
1
CPU_1 Pwrdwn drive mode
1 = Hi-Z, 0 = Driven in Pwrdwn
RW
0 = Driven in
power down
CPU_1 & CPU_1#
40, 41
NA
2
CPU_2 Pwrdwn drive mode
1 = Hi-Z, 0 = Driven in Pwrdwn
RW
0 = Driven in
power down
CPU_2 & CPU_2#
35, 36
NA
3
SRC_Pwrdwn drive mode
1 = Hi-Z, 0 = Driven in Pwrdwn
RW
0 = Driven in
power down
SRC[0:7] &
SRC[0:7]#
17, 18, 19, 20, 22,
23, 24, 25, 26, 27,
30, 31, 32, 35, 36
NA
4
CPU_0 Stop drive mode
1 = Hi-Z, 0 = Driven in CPU Stop
RW
0 = Driven in
CPU_STOP
CPU_0 & CPU_0#
43, 44
NA
5
CPU_1 Stop drive mode
1 = Hi-Z, 0 = Driven in CPU Stop
RW
0 = Driven in
CPU_STOP
CPU_1 & CPU_1#
40, 41
NA
6
CPU_2 Stop drive mode
1 = Hi-Z, 0 = Driven in CPU Stop
RW
0 = Driven in
CPU_STOP
CPU_2 & CPU_2#
35, 36
NA
7
SRC_Stop drive mode
1 = Hi-Z, 0 = Driven in PCI Stop
RW
0 = Driven in
PCI_STOP
SRC[0:7] &
SRC[0:7]#
17, 18, 19, 20, 22,
23
24, 25, 26, 27, 30,
31
32, 33, 35, 36
NA
08-0298
