MAXQ610
16-Bit Microcontroller with Infrared Module
10
______________________________________________________________________________________
Pin Description (continued)
PIN
32 TQFN
40 TQFN
44 TQFN
NAME
FUNCTION
General-Purpose, Digital, I/O, Type-C Port. These port pins function as
bidirectional I/O pins. P2.0–P2.3 default to high-impedance mode after a reset.
Software must configure these pins after release from reset to remove the high-
impedance input condition. All alternate functions must be enabled from
software. Enabling the pin’s special function disables the general-purpose I/O
on the pin.
The JTAG pins (P2.4–P2.7) default to their JTAG function with weak pullups
enabled after a reset. The JTAG function can be disabled using the TAP bit in
the SC register.
P2.7 functions as the JTAG test-data output on reset and defaults to an input
with a weak pullup. The output function of the test data is only enabled during
the TAP’s Shift_IR or Shift_DR states.
32 TQFN
40 TQFN
44 TQFN
PORT
SPECIAL FUNCTION
—
25
27
P2.0
MOSI
—
26
29
P2.1
MISO
—
29
32
P2.2
SCLK
—
30
33
P2.3
SSEL
24
31
34
P2.4
TCK
25
32
35
P2.5
TDI
26
35
38
P2.6
TMS
24–27
25, 26,
29–32,
35, 36
27, 29,
32–35,
38, 39
P2.0–
P2.7;
MOSI,
MISO,
SCLK,
SSEL,
TCK, TDI,
TMS,
TDO
27
36
39
P2.7
TDO
General-Purpose, Digital, I/O, Type-D Port; External Edge-Selectable Interrupt.
These port pins function as bidirectional I/O pins or as interrupts. All port pins
default to high-impedance mode after a reset. Software must configure these
pins after release from reset to remove the high-impedance input condition. All
interrupt functions must be enabled from software.
32 TQFN
40 TQFN
44 TQFN
PORT
SPECIAL FUNCTION
—
2
P3.0
INT8
—
4
P3.1
INT9
—
15
P3.2
INT10
—
16
P3.3
INT11
—
27
30
P3.4
INT12
—
28
31
P3.5
INT13
—
33
36
P3.6
INT14
—
2, 4, 15,
16, 27,
28, 33, 34
2, 4, 15,
16, 30,
31, 36,
37
P3.0–
P3.7;
INT8–
INT15
—
34
37
P3.7
INT15
NO CONNECTION PINS
23
—
N.C.
No Connection. Reserved for future use. Leave this pin unconnected.
