91
SINGLE-CHIP 8-BIT CMOS MICROCOMPUTER with CLOSED CAPTION DECODER
and ON-SCREEN DISPLAY CONTROLLER
M37280MF–XXXSP, M37280MK–XXXSP
M37280EKSP
MITSUBISHI MICROCOMPUTERS
PRELIMINAR
Y
Notice:
This
is not
a final
specification.
Some
paramentic
limits
are
subject
to change.
Rev. 1.0
12.11.7 Character Color
As shown in Figure 2.11.24, there are 16 built-in color pallets. Color
pallet 0 is fixed at transparent, and color pallet 8 is fixed at black.
The remaining 14 colors can be set to any of the 64 colors available.
The setting procedure for character colors is as follows:
CC mode ................................. 8 kinds
Color pallet selection range (color pallets 0 to 7 or 8 to 15) can be
selected by bit 0 of the OSD control register 3 (address 021916).
Color pallets are set by bits RC11 to RC13 of the OSD RAM from
among the selection range.
OSD mode .............................. 15 kinds
Color pallets are set by bits RC11 to RC14 of the OSD RAM.
CDOSD mode ......................... 8 kinds
Color pallet selection range (color pallets 0 to 7 or 8 to 15) can be
selected by bit 3 of the OSD control register 3 (address 021916).
Color pallets are set in dot units according to the CD font data (the
OSD RAM<color dot font> contents)from among the selection
range.
Only in CDOSD mode, a dot which selects color pallet 0 or 8 is
colored to the color pallet set by RC13 to RC16 of OSD RAM in
character units.
SPRITE display ....................... 8 kinds
Color pallet selection range (color pallets 0 to 7 or 8 to 15) can be
selected by bit 4 of the OSD control register 3 (address 021916).
Color pallets are set in dot units according to the CD font data (the
OSD RAM<color dot font> contents) from among the selection
range.
Notes 1: Color pallet 8 is always selected for bordering and solid space output
(OUT 1 output) regardless of the set value in the register.
2: Color pallet 0 (transparent) and the transparent setting of other color
pallets will differ. When there are multiple layers overlapping (on top
of each other, piled up), and the priority layer is color pallet 0 (trans-
parent), the bottom layer is displayed, but if the priority layer is the
transparent setting of any other color pallet, the background is dis-
played without displaying the bottom layer (refer to Figure 12.11.26).
12.11.8 Character Background Color
The display area around the characters can be colored in with a char-
acter background color. Character background colors are set in
character units.
CC mode ................................. 4 kinds
Color pallet selection range (color pallets 0 to 3, 4 to 7, 8 to 11, or
12 to 15) can be selected by bits 1 and 2 of the OSD control
register 3 (address 021916). Color pallets are set by bits RC20
and RC21 of the OSD RAM from among the selection range.
OSD mode .............................. 15 kinds
Color pallets are set by bits RC15, RC16, RC20, and RC21 of the
OSD RAM.
Note : The character background is displayed in the following part:
(character display area) – (character font) – (border).
Accordingly, the character background color and the color signal for
these two sections cannot be mixed.
