1
FN6093.2
ISL43L220
Ultra Low ON-Resistance, Low Voltage,
Single Supply, Dual SPDT Analog Switch
The Intersil ISL43L220 device is a low ON-resistance, low
voltage, bidirectional, dual single-pole/double-throw (SPDT)
analog switch designed to operate from a single +1.1V to
+4.5V supply. Targeted applications include battery powered
equipment that benefit from low R
ON
(0.22
)
and fast
switching speeds (t
ON
= 11ns, t
OFF
= 5ns). The digital logic
input is 1.8V logic-compatible when using a single +3V supply.
Cell phones, for example, often face ASIC functionality
limitations. The number of analog input or GPIO pins may be
limited and digital geometries are not well suited to analog
switch performance. This part may be used to “mux-in”
additional functionality while reducing ASIC design risk. The
ISL43L220 is offered in a small form factor package,
alleviating board space limitations.
The ISL43L220 is a committed dual single-pole/double-throw
(SPDT) that consist of two normally open (NO) and two
normally closed (NC) switches. This configuration can also be
used as a dual 2-to-1 multiplexer. The ISL43L220 is pin
compatible with the MAX4684 and MAX4685.
Features
Pb-Free Available as an Option (RoHS Compliant)
(See Ordering Info)
ON Resistance (R
ON
)
- V+ = +4.3V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.22
- V+ = +3.0V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.26
- V+ = +1.8V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.5
R
ON
Matching Between Channels. . . . . . . . . . . . . . . . 0.03
R
ON
Flatness Across Signal Range . . . . . . . . . . . . . . 0.03
Single Supply Operation. . . . . . . . . . . . . . . . . +1.1V to +4.5V
Low Power Consumption (PD). . . . . . . . . . . . . . . . . . <0.3μW
Fast Switching Action (V+ = +4.3V)
- t
ON
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11ns
- t
OFF
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5ns
Guaranteed Break-Before-Make
1.8V Logic Compatible (+3V supply)
Available in 10 lead 3x3 thin DFN
ESD HBM Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . >9kV
Applications
Battery powered, handheld, and portable equipment
- Cellular/mobile phones
- Pagers
- Laptops, notebooks, palmtops
Portable Test and Measurement
Medical Equipment
Audio and video switching
Related Literature
Technical Brief TB363 “Guidelines for Handling and
Processing Moisture Sensitive Surface Mount Devices
(SMDs)”
Application Note AN557 “Recommended Test Procedures
for Analog Switches”
TABLE 1. FEATURES AT A GLANCE
ISL43L220
Number of Switches
2
SW
SPDT or 2-1 MUX
4.3V R
ON
0.22
4.3V t
ON
/t
OFF
11ns/5ns
3V R
ON
0.26
3V t
ON
/t
OFF
14ns/6ns
1.8V R
ON
0.5
1.8V t
ON
/t
OFF
20ns/8ns
Packages
10Ld 3x3 thin DFN
Data Sheet
April 12, 2005
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 1-888-352-6832
Intersil (and design) is a registered trademark of Intersil Americas Inc.
Copyright Intersil Americas Inc. 2004, 2005. All Rights Reserved
All other trademarks mentioned are the property of their respective owners.
