3
FN6053.3
March 13, 2006
Absolute Maximum Ratings
Thermal Information
V+ to V- . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.3 to15V
V+ to GND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.3 to15V
V- to GND. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -15 to 0.3V
Input Voltages
LE, EN, EN , NO, NC, ADD (Note 1) . . . . . . -0.3 to ((V+) + 0.3V)
Output Voltages
COM (Note 1). . . . . . . . . . . . . . . . . . . . . . . . -0.3 to ((V+) + 0.3V)
Continuous Current (Any Terminal) . . . . . . . . . . . . . . . . . . . .
±
30mA
Peak Current NO, NC, or COM
(Pulsed 1ms, 10% Duty Cycle, Max) . . . . . . . . . . . . . . . .
±
100mA
ESD Rating
HBM ( Per Mil-STD-883, Method 3015.7) . . . . . . . . . . . . .
>2.5kV
Operating Conditions
Temperature Range
ISL43681IR and ISl43741IR . . . . . . . . . . . . . . . . . . . -40°C to 85°C
Thermal Resistance (Typical, Note 2)
20 Ld 4x4 QFN Package . . . . . . . . . . . . . . . . . . . . .
Maximum Junction Temperature (Plastic Package). . . . . . . . 150°C
Maximum Storage Temperature Range . . . . . . . . . . . . . -65°C to 150°C
Maximum Lead Temperature (Soldering 10s) . . . . . . . . . . . . 300°C
(Lead Tips Only)
θ
JA
(°C/W)
45
CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.
NOTES:
1. Signals on NC, NO, COM, ADD, EN, EN, or LE exceeding V+ or V- are clamped by internal diodes. Limit forward diode current to maximum
current ratings.
2.
θ
JA
is measured with the component mounted on a high effective thermal conductivity test board with direct die attach. See Tech Brief TB379
for details.
Electrical Specifications ±5V Supply
Test Conditions: V
SUPPLY
=
±
4.5V to
±
5.5V, GND = 0V, V
INH
= 2.4V, V
INL
= 0.8V (Note 3),
Unless Otherwise Specified
PARAMETER
TEST CONDITIONS
TEMP
(°C)
(NOTE 4)
MIN
TYP
(NOTE 4)
MAX
UNITS
ANALOG SWITCH CHARACTERISTICS
Analog Signal Range, V
ANALOG
Full
V-
-
V+
V
ON Resistance, R
ON
V
S
=
±
4.5V, I
COM
= 2mA, V
NO
or V
NC
= 3V
(See Figure 6)
25
-
44
60
Full
-
-
80
R
ON
Matching Between Channels,
R
ON
V
S
=
±
4.5V, I
COM
= 2mA, V
NO
or V
NC
= 3V (Note 5)
25
-
1.3
4
Full
-
-
6
R
ON
Flatness, R
FLAT(ON)
V
S
=
±
4.5V, I
COM
= 2mA, V
NO
or V
NC
=
±
3V, 0V
(Note 6)
25
-
7.5
9
Full
-
-
12
NO or NC OFF Leakage Current,
I
NO(OFF)
or I
NC(OFF)
V
S
=
±
5.5V, V
COM
=
±
4.5V, V
NO
or V
NC
= +4.5V
(Note 7)
25
-0.1
0.002
0.1
nA
Full
-2.5
-
2.5
nA
COM OFF Leakage Current,
I
COM(OFF)
V
S
=
±
5.5V, V
COM
=
±
4.5V, V
NO
or V
NC
= +4.5V
(Note 7)
25
-0.1
0.002
0.1
nA
Full
-2.5
-
2.5
nA
COM ON Leakage Current,
I
COM(ON)
V
S
=
±
5.5V, V
COM
= V
NO
or V
NC
=
±
4.5V (Note 7)
25
-0.1
0.002
0.1
nA
Full
-2.5
-
2.5
nA
DIGITAL INPUT CHARACTERISTICS
Input Voltage High, V
INH
, V
ADDH
Full
2.4
-
-
V
Input Voltage Low, V
INL
, V
ADDL
Full
-
-
0.8
V
Input Current, I
ADDH
, I
ADDL,
I
ENH,
I
ENL
V
S
=
±
5.5V, V
INH
, V
ADD
= 0V or V+
Full
-0.5
-
0.5
μA
Input Current, I
ENH
, I
LEH
V
S
=
±
5.5V, V
INH
, V
ADD
= 0V or V+
Full
-1.5
-
1.5
μA
Input Current, I
ENL
, I
LEL
V
S
=
±
5.5V, V
INH
, V
ADD
= 0V or V+
Full
-4
-
4
μA
ISL43681, ISL43741
