DAC1405D750
All information provided in this document is subject to legal disclaimers.
NXP B.V. 2011. All rights reserved.
Product data sheet
Rev. 4 — 7 June 2011
28 of 42
NXP Semiconductors
DAC1405D750
Dual 14-bit DAC, up to 750 Msps; 4
and 8
interpolating
10.9 DAC transfer function
The full-scale output current for each DAC is the sum of the two complementary current
outputs:
(3)
The output current depends on the digital input data:
(4)
(5)
The setting applied to CODING (register 00h[2]; see
Table 9 “Register allocation map”
)
defines whether the DAC1405D750 operates with a binary input or a two’s complement
input.
Table 38
shows the output current as a function of the input data, when I
O(fs)
= 20 mA.
Table 38.
Data
10.10 Full-scale current
10.10.1
Regulation
The DAC1405D750 reference circuitry integrates an internal bandgap reference voltage
which delivers a 1.25 V reference to the GAPOUT pin. It is recommended to decouple pin
GAPOUT using a 100 nF capacitor.
The reference current is generated via an external resistor of 910
(1 %) connected to
pin VIRES. A control amplifier sets the appropriate full-scale output current (I
O(fs)
) for both
DACs (see
Figure 11
).
DAC transfer function
I13 to I0 and Q13 to Q0
Binary
00 0000 0000 0000
...
10 0000 0000 0000
...
11 1111 1111 1111
IOUTP (mA)
IOUTN (mA)
Two’s complement
10 0000 0000 0000
...
00 0000 0000 0000
...
01 1111 1111 1111
0
...
8192
...
16383
0
...
10
...
20
20
...
10
...
0
I
O fs
I
IOUTP
I
IOUTN
+
=
I
IOUTP
I
O fs
16383
---------------
=
I
IOUTN
I
O fs
------------------------------------
16383
=
