3
Figure 2. Package Outline Drawing
Note:
YYWW
ManufacturedWorkWeek
COO
CountryOfOrigin(Philippines)
FRONT VIEW
13.97
(0.55)
MIN.
4.5 ±0.2
(0.177 ±0.008)
(PCB to OPTICS
CENTER LINE)
5.15
(0.20)
(PCB to OVERALL
RECEPTACLE CENTER
LINE)
DIMENSIONS IN MILLIMETERS (INCHES)
NOTES:
1. THIS PAGE DESCRIBES THE MAXIMUM PACKAGE OUTLINE, MOUNTING STUDS, PINS AND THEIR RELATIONSHIPS TO EACH OTHER.
2. TOLERANCED TO ACCOMMODATE ROUND OR RECTANGULAR LEADS.
3. ALL 12 PINS AND POSTS ARE TO BE TREATED AS A SINGLE PATTERN.
4. THE MT-RJ HAS A 750 m FIBER SPACING.
5. THE MT-RJ ALIGNMENT PINS ARE IN THE MODULE.
6. FOR SM MODULES, THE FERRULE WILL BE PC POLISHED (NOT ANGLED).
7. SEE MT-RJ TRANSCEIVER PIN OUT DIAGRAM FOR DETAILS.
37.56 (1.479) MAX.
SIDE VIEW
49.56 (1.951) REF.
9.8
(0.386)
MAX.
9.3
(0.366)
MAX.
1.07
(0.042)
0.61
(0.024)
Pin 1
TOP VIEW
9.6
(0.378)
MAX.
13.59
(0.535)
MAX.
12
(0.472)
7.59
(0.299)
8.6
(0.339)
1.5
(0.059)
17.778
(0.7)
1.778
(0.07)
7.112
(0.28)
+0
-0.2
(+000)
(-008)
10.16
(0.4)
Case Temperature
Measurement Point
Min 2.92
(0.115)
Labelling Information
