參數資料
型號： AD8326AREZ
廠商： Analog Devices Inc
文件頁數： 15/24頁
文件大?。?/td> 0K
描述： IC LINE DVR CATV PROG 28TSSOP
產品變化通告： AD8326 Series Discontinuation 28/Feb/2012
標準包裝： 50
類型： 線路驅動器，發射器
應用： CATV
安裝類型： 表面貼裝
封裝/外殼： 28-SOIC（0.173"，4.40mm 寬）裸露焊盤
供應商設備封裝： 28-HTSSOP
包裝： 管件
REV. 0
AD8326
–22–
AD8326 Evaluation Board Rev. B – Revised - November 22, 2000
Qty.
Description
Vendor
Ref Description
2
10
F 16 V. B Size Tantalum Chip Capacitor
ADS# 4-7-24
C7, C19
4
0.1
F 50 V. 1206 Size Ceramic Chip Capacitor
ADS# 4-5-18
C20–23
14
0.1
F 25 V. 603 Size Ceramic Chip Capacitor
ADS# 4-12-8
C4–C6, C8–C18
90
1/8 W. 1206 Size Chip Resistor
ADS# 3-18- 88
R1–R3, R7, R8, R13, R14,
R18, R19
1
78.7
1% 1/8 W. 1206 Size Chip Resistor
ADS# 3-18-194
R12
2
Yellow Test Point [INPUTS] (Bisco TP104-01-04)
ADS# 12-18-32
TP13, TP14
6
White Test Point [DATA] (Bisco TP104-0 -09)
ADS# 12-18-42
TP1–TP6
1
Red Test Point [VCC] (Bisco TP104-01-02)
ADS# 12-18-43
TP15
1
Blue Test Point [VEE] (Bisco TP104-01-06)
ADS# 12-18-62
TP7
3
Black Test Point [AGND] (Bisco TP104-01-00)
ADS# 12-18-44
TP16–TP18
4
End Launch SMA Connector
ADS# 12-1-31
VIN–, VIN+, CABLE,
HPF
1
Centronics Type 36 Pin Right-Angle Connector
ADS# 12-3-50
P1
1
3 Terminal Power Block (Green)
ADS# 12-19-14
TB1
1
1:1 Transformer TOKO # 617DB – A0070
TOKO
T3, T1
1
Pulse # CX 6002 Diplexer
PULSE
Z2
1
AD 8326ARE (TSSOP ePad) UPSTREAM Cable Driver
ADI# AD8326XRE
Z1
1
AD 8326ARE REV. B Evaluation PC Board
ADI# AD8326XRE-EVAL
EVAL PCB
4#4–40
× 1/4 Inch STAINLESS Panhead Machine Screw
ADS# 30-1-1
4#4–40
× 3/4 Inch Long Aluminum Round Standoff
ADS# 30-16-3
2# 2–56
× 3/8 inch STAINLESS Panhead Machine Screw
ADS# 30-1-17
(p1 hardware)
2
# 2 Steel Flat Washer
ADS# 30-6-6
(p1 Hardware)
2
# 2 Steel Internal Tooth Lockwasher
ADS# 30-5-2
(p1 Hardware)
2
# 2 STAINLESS STEEL Hex. Machine Nut
ADS# 30-7-6
(p1 Hardware)
Do not install C1–C3, R4–R6, R10, R11, R15–R17, T2, T4, TP8–TP12, W1–W2.
