Philips Semiconductors
Product specification
Rectifier diodes
PBYL1025B series
Schottky barrier
THERMAL RESISTANCES
SYMBOL PARAMETER
CONDITIONS
MIN.
TYP. MAX. UNIT
R
th j-mb
Thermal resistance junction
-
3
K/W
to mounting base
R
th j-a
Thermal resistance junction
pcb mounted, minimum footprint, FR4
-
50
-
K/W
to ambient
board
ELECTRICAL CHARACTERISTICS
T
j = 25 C unless otherwise specified
SYMBOL PARAMETER
CONDITIONS
MIN.
TYP. MAX. UNIT
V
F
Forward voltage
I
F = 10 A; Tj = 150C
-
0.33
0.4
V
I
F = 10 A; Tj = 125C
-
0.39
0.45
V
I
F = 20 A; Tj = 125C
-
0.54
0.61
V
I
F = 20 A
-
0.57
0.64
V
I
R
Reverse current
V
R = VRWM
-
0.2
5
mA
V
R = VRWM; Tj = 100C
-
15
30
mA
C
d
Junction capacitance
V
R = 5 V; f = 1 MHz, Tj = 25C to 125C
-
580
-
pF
October 1998
2
Rev 1.100
