COMMERCIALANDINDUSTRIAL
TEMPERATURERANGES
IDT723631/723641/723651 CMOS SyncFIFO
512 x 36, 1,024 x 36 and 2,048 x 36
5
IDT723631
IDT723641
IDT723651
Commercial & Industrial(1)
tA = 15, 20 ns
Parameter
Test Conditions
Min.
Typ.(2)
Max.
Unit
VOH
VCC = 4.5V,
IOH = –4 mA
2.4
—
V
VOL
VCC = 4.5V,
IOL = 8 mA
—
0.5
V
ILI
VCC = 5.5V,
VI = VCC or 0
—
±5
A
ILO
VCC = 5.5V,
VO = VCC or 0
—
±5
A
ICC
VCC = 5.5V,
VI = VCC –0.2V or 0
—
400
A
ICC(3,4)
VCC = 5.5V,
One Input at 3.4V,
CSA = VIH
A0-A35
—
0
—
mA
Other Inputs at VCC or GND
CSB = VIH
B0-B35
—
0
—
CSA = VIL
A0-A35
—
1
CSB = VIL
B0-35
—
1
All Other Inputs
—
1
CIN
VI = 0,
f = 1 MHz
—
4
—
pF
COUT
VO = 0,
f = 1 MHZ
—
8
—
pF
ABSOLUTE MAXIMUM RATINGS OVER OPERATING FREE-AIR TEMPERATURE
RANGE (UNLESS OTHERWISE NOTED)(2)
Symbol
Rating
Commercial
Unit
VCC
Supply Voltage Range
–0.5 to 7
V
VI(2)
Input Voltage Range
–0.5 to VCC+0.5
V
VO(2)
Output Voltage Range
–0.5 to VCC+0.5
V
IIK
Input Clamp Current, (VI < 0 or VI > VCC)
±20
mA
IOK
Output Clamp Current, (VO = < 0 or VO > VCC)
±50
mA
IOUT
Continuous Output Current, (VO = 0 to VCC)
±50
mA
ICC
Continuous Current Through VCC or GND
±400
mA
TSTG
Storage Temperature Range
–65 to 150
°C
ELECTRICAL CHARACTERISTICS OVER RECOMMENDED OPERATING
FREE-AIR TEMPERATURE RANGE (UNLESS OTHERWISE NOTED)
NOTES:
1. Industrial temperature range product for 20ns is available as a standard device.
2. All typical values are at VCC = 5V, TA = 25
°C.
3. This is the supply current when each input is at least one of the specified TTL voltage levels rather than 0V or VCC.
4. For additional ICC information, see the following page.
NOTES:
1. Stresses beyond those listed under "Absolute Maximum Ratings" may cause permanent damage to the device. These are stress ratings only and functional operation of the
device at these or any other conditions beyond those indicated under "Recommended Operating Conditions" is not implied. Exposure to absolute-maximum-rated conditions
for extended periods may affect device reliability.
2. The input and output voltage ratings may be exceeded provided the input and output current ratings are observed.
Symbol
Parameter
Min.
Max.
Unit
VCC
Supply Voltage
4.5
5.5
V
VIH
HIGH Level Input Voltage
2
—
V
VIL
LOW-Level Input Voltage
—
0.8
V
IOH
HIGH-Level Output Current
—
–4
mA
IOL
LOW-Level Output Current
—
8
mA
TA
Operating Free-air Temperature
0
70
°C
RECOMMENDED OPERATING CONDITIONS
