參數資料
| 型號： | 2SC5336-T1RE |
| 元件分類： | 小信號晶體管 |
| 英文描述： | UHF BAND, Si, NPN, RF SMALL SIGNAL TRANSISTOR |
| 封裝： | POWER, MINIMOLD PACKAGE-4 |
| 文件頁數： | 2/8頁 |
| 文件大?。?/td> | 47K |
| 代理商： | 2SC5336-T1RE |
Data Sheet P10938EJ2V0DS
2
2SC5336
ELECTRICAL CHARACTERISTICS (TA = +25
°°°°C)
Parameter
Symbol
Test Conditions
MIN.
TYP.
MAX.
Unit
DC Characteristics
Collector Cut-off Current
ICBO
VCB = 10 V, IE = 0 mA
–
1.0
A
Emitter Cut-off Current
IEBO
VBE = 1 V, IC = 0 mA
–
1.0
A
DC Current Gain
hFE
Note 1
VCE = 10 V, IC = 20 mA
50
120
250
–
RF Characteristics
Gain Bandwidth Product
fT
VCE = 10 V, IC = 20 mA
–
6.5
–
GHz
Insertion Power Gain
S21e2 VCE = 10 V, IC = 20 mA, f = 1 GHz
–
12
–
dB
Noise Figure (1)
NF
VCE = 10 V, IC = 7 mA, f = 1 GHz
–
1.1
–
dB
Noise Figure (2)
NF
VCE = 10 V, IC = 40 mA, f = 1 GHz
–
1.8
3.0
dB
Reverse Transfer Capacitance
Cre
Note 2
VCB = 10 V, IE = 0 mA, f = 1 MHz
–
0.5
0.8
pF
Notes 1. Pulse measurement: PW
≤ 350
s, Duty Cycle ≤ 2%
2. Collector to base capacitance when the emitter grounded
hFE CLASSIFICATION
Rank
RH
RF
RE
Marking
RH
RF
RE
hFE Value
50 to 100
80 to 160
125 to 250
