1/5
TPDV625 ---> TPDV1225
September 2001 - Ed: 1A
ALTERNISTORS
I
High commutation: > 88A/ms (400Hz)
I
Insulating voltage = 2500V
(RMS)
(UL Recognized: EB81734)
I
High voltage capability: V
DRM
= 1200V
FEATURES
The TPDV625 ---> TPDV1225 use a high perfor-
mance passivated glass alternistor technology.
Featuring very high commutation levels and high
surge current capability, this family is well adapted
to power control on inductive load (motor, trans-
former...)
DESCRIPTION
A1
A2
G
TOP3
Symbol
I
T(RMS)
I
TSM
Parameter
Value
25
390
250
230
265
20
Unit
A
A
RMS on-state current (360° conduction angle)
Non repetitive surge peak on-state current
(Tj initial = 25°C)
Tc = 85°C
tp = 2.5ms
tp = 8.3ms
tp = 10ms
tp = 10ms
Repetitive
F = 50Hz
Non repetitive
I
2
t
I
2
t value
Critical rate of rise of on-state current
Gate supply: I
G
= 500mA
A
2
s
A/μs
dI/dt
dI
G
/dt = 1A/μs
100
Tstg
Tj
Tl
Storage and operating junction temperature range
-40 to +150
-40 to +125
260
°C
Maximum lead soldering temperature during 10s at 4.5mm from case
°C
ABSOLUTE RATINGS
(limiting values)
Symbol
Parameter
TPDV
Unit
625
825
1025
1225
V
DRM
V
RRM
Repetitive peak off-state voltage
Tj = 125°C
600
800
1000
1200
V
A1
A2
G
